Siemens 6AG1223-3AD30-5XB0 VDC Logic I/O Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Model |
|
|
Brand |
|
|
Product Series |
SIPLUS S7-1200 |
|
Product Type |
SB 1223 Digital Input/Output Module |
|
Base Model |
6ES7223-3AD30-0XB0 |
|
Number of Digital Inputs |
2 |
|
Number of Digital Outputs |
2 |
|
Rated Signal Voltage |
5 V DC |
|
Input Type |
Digital, current-sourcing |
|
Output Type |
Solid-state MOSFET |
|
Maximum Output Current |
0.1 A per channel |
|
Maximum Output Switching Frequency |
200 kHz |
|
Typical Backplane Bus Current |
35 mA at 5 V DC |
|
Typical Power Dissipation |
0.5 W |
|
Input Delay |
Configurable, including microsecond and millisecond ranges |
|
Maximum Cable Length |
50 m with shielded, twisted-pair cable |
|
Short-Circuit Protection |
Not integrated |
|
Diagnostic Functions |
Input/output status and diagnostic information |
|
Engineering Software |
STEP 7 / TIA Portal |
|
Protective Coating |
Conformal coating |
|
Operating Temperature Range |
-40°C to +60°C |
|
Minimum Startup Temperature |
-25°C |
|
Dimensions |
80 × 50 × 28 mm |
|
Weight |
0.031 kg |
FAQ
1. What is the Siemens 6AG1223-3AD30-5XB0 used for?
The 6AG1223-3AD30-5XB0 is a SIPLUS S7-1200 signal board designed to handle digital input and output signals in compact automation systems. It supports applications requiring fast signal processing and a small I/O footprint.
2. How many digital inputs and outputs does this module provide?
The module provides two digital inputs and two digital outputs. It can be used to connect compatible digital signal devices to an S7-1200 PLC system.
3. What signal voltage does the 6AG1223-3AD30-5XB0 use?
The module is designed for 5 V DC digital signals. Confirm the electrical characteristics of the connected sensors and devices before wiring to avoid signal incompatibility.
4. What type of output does this module use?
It uses solid-state MOSFET digital outputs. The maximum output current is 0.1 A per channel, so the connected load must remain within the specified electrical limits.
5. Can the module handle high-speed signals?
Yes. The module supports operation at up to 200 kHz under suitable conditions. Actual performance depends on signal timing, wiring, configuration, and the capabilities of the overall PLC application.
6. Is output short-circuit protection integrated?
No. Integrated output short-circuit protection is not provided. Appropriate external circuit protection should be considered when designing the wiring and selecting connected loads.
7. Which engineering software is used to configure the module?
The module is configured within the Siemens STEP 7 engineering environment through TIA Portal. The supported configuration options depend on the project setup and the applicable software version.
8. What should be checked if the module does not respond correctly?
Check the PLC configuration, module compatibility, wiring polarity, 5 V DC signal levels, connected load current, and input/output status in the engineering software. Also inspect the installation environment and verify that the application uses compatible signal timing settings.
Siemens 6AG1223-3AD30-5XB0 VDC Logic I/O Module is in stock. Please contact us for a quick quote and competitive pricing.
