Yokogawa ADR541-P10 Relay Output Module
Product Overview
The Yokogawa ADR541-P10 is a high-performance relay output module designed for use within Yokogawa’s CENTUM or ProSafe programmable control platforms. This module provides reliable relay-based discrete output control for industrial systems, making it ideal for switching field devices such as solenoids, indicators, alarms, and contactors.
With 16 relay output channels and built-in isolation features, the ADR541-P10 offers robust performance for critical applications requiring mechanical relay contact integrity. It supports safe and efficient control operations in demanding environments, such as power generation, petrochemical processing, and water treatment facilities.
Key Features
-
16-Channel Relay Output – Offers 16 independent relay output points for controlling a wide range of external devices
-
High Isolation – Optical and mechanical isolation between channels and system bus ensures noise immunity and operational stability
-
Fail-Safe Design – Configurable default output states on failure for enhanced system reliability
-
LED Status Indicators – Front-panel indicators provide real-time status monitoring for each output channel
-
Field Replaceable – Easy installation and maintenance with modular design and standardized terminal blocks
-
Industrial Reliability – Built for use in harsh industrial conditions with durable construction and tested endurance
Technical Specifications
Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 130 x 32.8 x 107.5 mm |
| Weight | 0.3 kg |
Electrical Characteristics
| Item | Specification |
|---|---|
| Output Type | Mechanical relay contacts (Form A) |
| Channels | 16 isolated outputs |
| Contact Rating | 30 VDC, 2 A / 250 VAC, 2 A |
| Output Isolation | 1500 V AC between outputs and system |
| Switching Time | ≤ 10 ms |
| Power Supply | Supplied from I/O backplane |
Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temp | 0°C to +60°C |
| Storage Temp | -20°C to +70°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Vibration Resistance | 10–57 Hz, 0.075 mm / 57–150 Hz, 9.8 m/s² |
| Enclosure Rating | Conforms to IEC standards |
System Compatibility
| Item | Specification |
|---|---|
| System Platform | Compatible with Yokogawa CENTUM CS 3000/VP, ProSafe-RS |
| Configuration Tool | Configurable via Yokogawa engineering tools |
| Terminal Module | Connects to appropriate Yokogawa FTA modules |
Industry Applications
-
Power Generation – For control and status feedback of breakers, interlocks, and alarms
-
Petrochemical and Refining – Controls solenoid valves, pumps, and alarm relays in hazardous areas
-
Water and Wastewater – Operates remote I/O relays for pump control and level alarms
-
Pharmaceuticals and Food Processing – Supports automated control tasks requiring clean relay outputs
-
Factory Automation – Provides discrete control signals for conveyors, actuators, and machine safety
The Yokogawa ADR541-P10 Relay Output Module is a dependable and flexible output solution designed to meet the control and reliability demands of complex industrial systems. Its robust relay architecture, modular design, and integration with Yokogawa control platforms make it an essential component for discrete signal management in high-reliability applications.
Yokogawa ADR541-P10 Relay Output Module is in stock. Please contact us for a quick quote and competitive pricing.
