GE Fanuc IC693MDL740F Discrete DC Output Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC693MDL740F |
| Manufacturer | GE Fanuc / Emerson |
| Product Series | Series 90-30 PLC |
| Product Type | Discrete DC Output Module |
| Main Function | Provides 16-channel digital DC transistor output control for driving external field devices |
| Application | Industrial automation, machine control, solenoid control, relay control, actuator control, indicator control |
| Output Type | Transistor output |
| Logic Type | Positive logic (Sourcing output) |
| Number of Outputs | 16 points |
| Output Configuration | 2 groups of 8 outputs |
| Rated Output Voltage | 12/24 VDC |
| Output Voltage Range | 12–24 VDC (+20%, -15%) |
| Output Current Rating | 0.5 A maximum per point |
| Output Current per Common | 2 A maximum |
| Inrush Current Capability | Approximately 4.78 A for 10 ms |
| Output Voltage Drop | Approximately 1 V maximum |
| Output Response Time | ON: 2 ms maximum / OFF: 2 ms maximum |
| External Power Supply | 12/24 VDC field power supply required |
| Backplane Current Consumption | Approximately 110 mA at 5 VDC |
| Isolation Type | Optical isolation between field side and logic side |
| Isolation Voltage | 1500 VAC for 1 minute |
| Protection Function | Output protection and fault monitoring |
| LED Indicators | Individual output status LEDs |
| Mounting Type | Series 90-30 PLC rack mounting |
| Installation Position | Any available Series 90-30 I/O slot |
| Terminal Connection | Removable terminal block |
| Compatible Modules | GE Fanuc / Emerson Series 90-30 CPU, power supply, and I/O modules |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | Approximately 130 mm × 125 mm × 35 mm |
| Weight | Approximately 0.3 kg |
| Compatibility | GE Fanuc / Emerson Series 90-30 PLC systems |
FAQ
Q1: What is the main function of the IC693MDL740F?
A: The IC693MDL740F is a Series 90-30 12/24 VDC positive logic output module used to control external DC devices such as relays, solenoid valves, contactors, and indicators.
Q2: How many output points does the IC693MDL740F provide?
A: The module provides 16 digital DC output points arranged into two groups of 8 outputs.
Q3: What type of output does the IC693MDL740F use?
A: It uses positive logic (sourcing) transistor outputs, supplying current from the positive power bus to connected loads.
Q4: What voltage and current can the outputs handle?
A: Each output supports 12/24 VDC operation with a maximum current rating of 0.5 A per point and 2 A per common.
Q5: Does the IC693MDL740F require an external power supply?
A: Yes. An external 12/24 VDC field power supply is required to operate connected field devices.
Q6: Does the IC693MDL740F provide isolation?
A: Yes. The module provides optical isolation between the field side and PLC logic side.
Q7: What should be checked before replacing an IC693MDL740F?
A: Verify Series 90-30 compatibility, output voltage requirements, load current, external DC supply, terminal wiring, and PLC configuration.
Q8: How can the reliability of the IC693MDL740F be maintained?
A: Use correct DC wiring, install suppression devices for inductive loads, avoid exceeding output current ratings, keep terminals secure, and maintain proper cabinet environmental conditions.
GE Fanuc IC693MDL740F Discrete DC Output Module is in stock. Please contact us for a quick quote and competitive pricing.
