ABB Bailey PHARPSCH100000 MPS III Power Supply Chassis
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | PHARPSCH100000 |
| Brand | ABB Bailey |
| Product Series | MPS III |
| Product Type | Power Supply Chassis |
| ABB Type Designation | MPS III |
| Catalog Description | Power Supply Chassis |
| System Application | ABB Bailey INFI 90 / Harmony DCS |
| Chassis Function | Provides the mechanical mounting and electrical distribution platform for MPS III power supply modules |
| Power Supply Support | Supports modular power supply trays and redundant power supply configurations |
| Cooling | Compatible with system monitoring and cooling fan assembly |
| Power Distribution | Provides connections for DC power distribution to the control-system cabinet |
| DC Bus Support | 5 VDC, ±15 VDC and 24 VDC power distribution |
| Field I/O Power | Supports dedicated 48 VDC and 125 VDC power connections where configured |
| Maintenance | Supports modular power-supply tray replacement |
| Typical Applications | DCS control systems, process automation, power generation and industrial automation |
| Installation | MPS III power supply chassis / cabinet installation |
| Dimensions | 540 × 230 × 550 mm |
| Weight | 3.8 kg |
FAQ
1. What is the ABB Bailey PHARPSCH100000 used for?
The PHARPSCH100000 is an MPS III Power Supply Chassis used as the mechanical and electrical foundation for ABB Bailey modular power-supply equipment. It provides mounting positions, power connections and distribution paths for the power supplies used within compatible DCS control-system cabinets.
2. How many power supply trays can the PHARPSCH100000 support?
The PHARPSCH100000 chassis is designed to accommodate two redundant power supply trays. This configuration allows the control system to use redundant power sources and supports higher availability for critical industrial control applications.
3. Which ABB Bailey power supplies can be installed in the PHARPSCH100000?
The chassis is associated with the ABB Bailey MPS III power-supply family. Compatible modules include MPS III power supplies such as PHARPS32000000 and PHARPS32010000. The exact replacement module should always be checked against the installed power-entry panel and system configuration.
4. What DC power connections are provided by the PHARPSCH100000?
The chassis provides power-distribution connections for the main MPS III DC bus, including 5 VDC, +15 VDC, -15 VDC and 24 VDC. Configured chassis installations may also provide 48 VDC and 125 VDC connections for field I/O devices.
5. Does the PHARPSCH100000 support redundant power operation?
Yes. The MPS III chassis is designed to support redundant power supply tray configurations. Using two compatible power supplies can provide redundancy for critical DCS power requirements, provided that the complete power-entry and distribution configuration is designed for redundant operation.
6. Can a power supply tray be replaced while the DCS is operating?
The MPS III architecture supports removal and replacement of power supply trays while the system remains online under the appropriate maintenance procedure. Before removing a tray, its associated power must be switched off at the Power Entry Panel to prevent power-fault indications or a possible process disturbance.
7. What role does the cooling fan play in the PHARPSCH100000 chassis?
The chassis works with the MPS III system monitoring and cooling fan assembly to provide airflow for the installed power-supply equipment. Proper fan operation is important for maintaining acceptable operating temperatures, particularly when the power supplies are operating under significant load.
8. What should be checked when troubleshooting a PHARPSCH100000 power chassis?
Troubleshooting should begin with the power-entry panel, chassis connections, power-supply tray installation and DC distribution wiring. Check the relevant power buses and status indications, then inspect the cooling fan and associated monitoring connections. If only one output or power tray is affected, isolate the corresponding power path before replacing the chassis or other DCS components.
ABB Bailey PHARPSCH100000 MPS III Power Supply Chassis is in stock. Please contact us for a quick quote and competitive pricing.
