Allen Bradley 2090-XXNPMF-16S15 Servo Feedback Cable
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 2090-XXNPMF-16S15 |
| Product Type | Servo Motor Power and Brake Cable |
| Product Series | Allen Bradley 2090-Series |
| Application | Kinetix Servo Motor Power and Brake Connection |
| Cable Type | Standard, Non-Flex |
| Jacket Material | Industrial TPE |
| Jacket Color | Black |
| Cable Length | 15 meters |
| Wire Gauge | 16 AWG |
| Power Conductors | Four conductors for three-phase motor power |
| Brake / Spare Conductors | Four additional 18 AWG shielded conductors |
| Power Voltage Rating | 600 V |
| Shielding | Shielded |
| Motor Connector | Straight Connector |
| Motor Interface | Threaded DIN Connector |
| Drive Compatibility | Kinetix motion control systems and compatible Allen Bradley servo drives |
| Cable Construction | Motor power, brake, and spare conductors |
| Cable Weight | Approx. 0.276 kg/m |
| Shipping Weight | 3 kg |
| UPC | 820919134135 |
| Country of Origin | Mexico |
FAQ
1. What is the main function of the Allen Bradley 2090-XXNPMF-16S15 cable?
The 2090-XXNPMF-16S15 is a standard non-flex motor power and brake cable used in Kinetix motion-control systems. It provides the electrical connection between a compatible servo motor and drive, carrying three-phase motor power as well as motor brake and spare conductors.
2. What does the 16S15 designation indicate?
The 16S15 designation identifies the cable configuration and length. The 16 refers to the 16 AWG power conductors, while S15 corresponds to the 15-meter cable configuration.
3. Is the 2090-XXNPMF-16S15 suitable for continuous-flex applications?
No. This model is a standard, non-flex cable intended primarily for fixed or relatively stationary installations. It should not normally be used in applications involving continuous robotic movement, repeated bending, or constant cable-carrier motion unless the specific installation conditions permit it.
4. What conductors are included in the 2090-XXNPMF-16S15?
The cable includes four 16 AWG conductors for three-phase motor power and additional 18 AWG shielded conductors for motor brake and spare connections. This construction allows power, brake, and auxiliary wiring to be integrated into a single servo motor cable assembly.
5. What is the voltage rating of the 2090-XXNPMF-16S15?
The cable has a 600 V power voltage rating. The actual operating voltage must remain within the requirements of the connected servo drive and motor. Proper grounding, shielding, and cable routing should also be maintained to support reliable servo operation.
6. Which Allen Bradley servo systems are compatible with this cable?
The 2090-XXNPMF-16S15 belongs to the Allen Bradley 2090-Series cable family and is intended for compatible Kinetix servo motor power and brake connections. The exact motor and drive catalog numbers should be verified before installation to confirm connector and wiring compatibility.
7. What should I check if the servo motor does not operate after cable installation?
Check that the motor connector and drive-side connections are fully seated and correctly wired. Verify the three-phase power connections, motor brake wiring, shield termination, and supply voltage. If the motor brake does not release, check the brake control circuit and voltage. Also inspect the cable for damaged conductors, loose terminals, or incorrect phase connections.
8. What installation precautions should be followed with this cable?
Avoid excessive bending, crushing, abrasion, and continuous mechanical movement because this is a non-flex cable. Route the cable away from sources of unnecessary mechanical stress and excessive heat. Maintain appropriate separation from sensitive feedback or communication wiring where required, and ensure that shielding and grounding are correctly terminated for the servo installation.
