Allen-Bradley 20BC535A3ANNNNC1 Variable Frequency AC Drive
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Manufacturer | Rockwell Automation |
| Model Number | 20BC535A3ANNNNC1 |
| Product Series | PowerFlex 700 |
| Product Type | Variable Frequency AC Drive (VFD) |
| Drive Bulletin | 20B |
| Input Voltage | 400 V AC |
| Input Phase | Three-phase |
| Rated Output Current | 535 A |
| Normal-Duty Power Rating | 300 kW |
| Heavy-Duty Power Rating | 280 kW |
| Frame Size | Frame 8 |
| Enclosure Rating | IP20 / NEMA Type 1, subject to configuration verification |
| Control Method | Vector Control |
| Operator Interface | LCD display with numeric keypad |
| Control I/O | 24 V DC, subject to installed configuration |
| Communication Interface | ControlNet, subject to installed option verification |
| Encoder Feedback | Supported, depending on installed option |
| Integral Braking IGBT | Not available for this frame size |
| Internal Braking Resistor | Not available for this frame size |
| Dimensions (H × W × D) | Approx. 2,349.1 × 1,025.9 × 757.9 mm (92.49 × 40.39 × 29.84 in); verify against the exact enclosure configuration |
| Approximate Drive Weight | 509 kg (1,122 lb) |
| Approximate Shipping Weight | 556 kg (1,225 lb) |
| Operating Temperature | Typically 0–40°C under standard conditions; verify derating requirements |
| Compatible Motor Type | Three-phase AC induction motor |
| Typical Applications | Pumps, fans, compressors, conveyors, and industrial process systems |
| Product Lifecycle | Discontinued; confirm spare-parts and repair availability |
FAQ
Q1: What is the Allen-Bradley 20BC535A3ANNNNC1?
A: The 20BC535A3ANNNNC1 is an industrial variable frequency AC drive associated with the Allen-Bradley PowerFlex 700 family. It regulates AC motor speed and torque for industrial machinery and process-control applications.
Q2: What are the rated voltage, output current, and power?
A: The corresponding drive configuration is rated for 400 V AC three-phase input and 535 A output. Published power ratings are approximately 300 kW for normal-duty applications and 280 kW for heavy-duty applications. Confirm the applicable ratings on the unit nameplate.
Q3: What are the dimensions of this drive?
A: The approximate dimensions for the referenced Frame 8 configuration are 2,349.1 mm high, 1,025.9 mm wide, and 757.9 mm deep. Confirm the enclosure type and mechanical drawing before allocating installation space.
Q4: How much does the 20BC535A3ANNNNC1 weigh?
A: The approximate drive weight is 509 kg (1,122 lb), with an estimated shipping weight of 556 kg (1,225 lb). Actual weight may vary with installed accessories and packaging. Confirm the lifting requirements before handling the unit.
Q5: Which motors are compatible with this drive?
A: The drive is designed for compatible three-phase AC motors. Check motor voltage, rated current, power, speed range, insulation requirements, and load characteristics to ensure that the drive is appropriately sized.
Q6: What communication and control features does it support?
A: Available features depend on the installed hardware and catalog options. The specified configuration is associated with vector control, 24 V DC control I/O, ControlNet communication, and encoder feedback. Verify the installed modules before integrating the drive with a PLC or automation network.
Q7: Does this drive have a built-in braking resistor?
A: This frame size does not include an integral braking IGBT or internal braking resistor. Applications requiring rapid deceleration may need a separately engineered braking solution compatible with the drive and the installation.
Q8: Is the Allen-Bradley 20BC535A3ANNNNC1 still available?
A: The PowerFlex 700 product family has been discontinued. Availability depends on remaining inventory, refurbished units, and repair services. Before purchasing a replacement, verify the complete catalog number, electrical ratings, physical dimensions, communication options, and equipment condition.
