Allen-Bradley MPL-B210E-V-X248 MPAS Linear Stage Spare Servo Motor
The Allen-Bradley MPL-B210E-V-X248 is a replacement servo motor designed for compatible Rockwell Automation MPAS ballscrew linear stages. It belongs to the MP-Series low-inertia brushless servo motor family and is intended for applications requiring precise, controlled linear movement. This configuration is specified for 400 V-class linear stages with a 5 mm-per-revolution ballscrew and does not include a holding brake.
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Model | MPL-B210E-V-X248 |
| Product Type | MPAS Linear Stage Replacement Servo Motor |
| Product Series | MP-Series |
| Application | MPAS Ballscrew Linear Stage |
| Voltage Class | 400 V |
| System Voltage | 460 V AC class |
| Frame Size | Frame 45 (130 mm) |
| Magnet Stack Length | 76.2 mm (3.0 in.) |
| Rated Speed | 4,000 RPM |
| Feedback Device | Single-turn high-resolution encoder |
| Shaft Type | Keyed shaft extension |
| Holding Brake | No brake |
| Connector | 7-pin SpeedTEC DIN connector, right-angle, rotatable |
| Mounting | Compatible MPAS linear-stage motor mounting |
| Ballscrew Pitch | 5 mm/revolution |
| Protection Rating | IP50 |
| Operating Temperature | 0–40°C |
| Dimensions | 4× 4× 14 mm |
| Weight | Approximately 4.54 kg (10 lb), based on distributor listing |
| Product Status | Active listing; confirm current availability |
FAQ
Q1: What is the Allen-Bradley MPL-B210E-V-X248?
It is a replacement servo motor for compatible MPAS linear stages, designed to provide controlled motion in industrial automation equipment.
Q2: What applications is this motor used for?
It is used with compatible ballscrew linear stages in automated assembly, positioning equipment, material handling, and other applications requiring precise linear movement.
Q3: What voltage class does this motor support?
The motor is associated with the 400 V class. Verify the exact motor and drive electrical requirements before installation.
Q4: Does the MPL-B210E-V-X248 include a holding brake?
No. This configuration is specified without a holding brake. Applications requiring load holding should be evaluated for an appropriate external mechanical solution.
Q5: What feedback system does this motor use?
It is specified with a single-turn high-resolution encoder. Confirm the feedback interface supported by the existing servo drive before replacement.
Q6: Which linear stage is compatible with this motor?
It is associated with compatible MPAS ballscrew linear stages using a 5 mm-per-revolution screw configuration. Confirm the complete stage catalog number before ordering.
Q7: What are the dimensions and weight of this motor?
The exact overall dimensions should be confirmed from the manufacturer’s mechanical drawing. A distributor lists the weight at approximately 4.54 kg (10 lb).
Q8: What should be checked before replacing this motor?
Verify the complete part number, voltage class, encoder compatibility, shaft and coupling dimensions, mounting interface, ballscrew pitch, and brake requirements. Confirm compatibility with the existing linear stage and servo drive before installation.
Allen-Bradley MPL-B210E-V-X248 MPAS Linear Stage Spare Servo Motor is in stock. Please contact us for a quick quote and competitive pricing.
