Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | HE693THM889B |
| Product Series | Horner Electric / GE Fanuc Compatible PLC I/O |
| Product Type | Thermocouple Input Module |
| Module Function | Provides temperature measurement capability by accepting thermocouple signals in industrial automation systems |
| Number of Input Channels | 8 channels |
| Input Type | Thermocouple temperature inputs |
| Supported Thermocouple Types | J, K, N, T, E, R, and S thermocouple types |
| Temperature Units | Degrees Celsius / Fahrenheit selectable |
| Input Resolution | 0.5°C |
| Conversion Method | Integrating A/D conversion |
| A/D Conversion Time | Approximately 5 ms |
| Input Impedance | Greater than 20 MΩ |
| Open Circuit Detection | Supported |
| Temperature Measurement Range | Depends on selected thermocouple type |
| Cold Junction Compensation | Built-in compensation function |
| Accuracy | Approximately ±0.5°C resolution performance |
| Isolation Type | Field input isolation from PLC logic circuits |
| Power Consumption | Approximately 70 mA at 5 VDC and 60 mA at 24 VDC supply |
| Communication Interface | PLC backplane communication |
| Configuration Method | PLC configuration software and module setup parameters |
| Diagnostic Features | Input monitoring, thermocouple fault detection, and module status diagnostics |
| Status Indicators | LED indicators for module operation and fault status |
| Installation Method | PLC rack-mounted installation |
| Compatibility | Horner Electric PLC I/O systems and compatible GE Fanuc automation platforms |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Dimensions | Approximately 130 × 35 × 125 mm (5.12 × 1.38 × 4.92 in) |
| Weight | Approximately 0.45 kg (1.0 lb) |
| Typical Applications | Temperature monitoring, heating control, process automation, ovens, furnaces, and industrial thermal measurement systems |
FAQ
Q1: What is the main function of the HE693THM889B?
A: The HE693THM889B is an 8-channel thermocouple input module designed for industrial PLC systems. It converts thermocouple temperature signals into digital values that can be processed by the controller.
Q2: How many thermocouple channels does the HE693THM889B provide?
A: The module provides eight independent thermocouple input channels, allowing multiple temperature points to be monitored simultaneously.
Q3: Which thermocouple types are supported by the HE693THM889B?
A: The module supports common thermocouple types including J, K, N, T, E, R, and S, making it suitable for different industrial temperature measurement requirements.
Q4: What is the resolution of the HE693THM889B temperature input?
A: The module provides 0.5°C resolution for temperature measurement, allowing stable and accurate monitoring of industrial processes.
Q5: Does the HE693THM889B support thermocouple fault detection?
A: Yes. The module supports open circuit detection to identify disconnected, damaged, or improperly connected thermocouple wiring.
Q6: What applications are suitable for the HE693THM889B?
A: The module is commonly used in furnace control, heating systems, industrial ovens, process monitoring, and automation applications requiring multiple temperature inputs.
Q7: How is the HE693THM889B configured in a PLC system?
A: The module is configured through PLC programming tools by selecting thermocouple types, measurement units, input channels, and operating parameters.
Q8: What should be checked when replacing a HE693THM889B module?
A: Verify PLC compatibility, thermocouple type, sensor wiring, channel configuration, power supply conditions, and control program settings before replacement.
GE Fanuc HE693THM889B Thermocouple Input Module is in stock. Please contact us for a quick quote and competitive pricing.
