GE Fanuc IC200MDL750B Discrete DC Output Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC200MDL750B |
| Product Series | GE Fanuc / Emerson VersaMax |
| Product Type | Discrete DC Output Module |
| Module Function | Provides high-density digital output control for VersaMax PLC systems and connected DC field devices |
| Output Points | 32 points |
| Output Configuration | Two groups of 16 outputs |
| Output Type | Positive Logic (Sourcing) DC Outputs |
| Output Voltage Range | +10.2 to +30 VDC |
| Nominal Output Voltage | 12/24 VDC |
| Output Current Rating | 0.5 A maximum per point at 30 VDC resistive load |
| Inrush Current Capacity | 2.0 A maximum for 100 ms |
| Output Voltage Drop | 0.3 V maximum |
| Output Leakage Current | 0.5 mA maximum at 30 VDC |
| Output Response Time | 0.2 ms maximum ON response; 1.0 ms maximum OFF response |
| External Power Supply | +10.2 to +30 VDC field supply required |
| Isolation Type | Optical isolation between field side and logic side |
| Group Isolation | 250 VAC continuous; 1500 VAC for 1 minute between groups |
| Point-to-Point Isolation | Not provided |
| Backplane Current Consumption | 90 mA maximum from 5 VDC backplane supply |
| Protection Features | External overload protection recommended; no internal output fuses |
| Status Indicators | Individual LED indicators for each output point, field power LED, and module status LED |
| Field Wiring | Two groups of 16 outputs with separate DC supply terminals |
| Installation Method | VersaMax carrier-based installation |
| Compatible Systems | GE Fanuc / Emerson VersaMax PLC systems |
| Module ID | 80808080 |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Dimensions | Approximately 109 × 64 × 58 mm (4.3 × 2.5 × 2.3 in) |
| Weight | Approximately 0.10 kg (0.22 lb) |
| Typical Applications | Motor control, solenoid operation, actuator switching, machine automation, and industrial digital output control |
FAQ
Q1: What is the main function of the IC200MDL750B?
A: The IC200MDL750B is a 32-point digital output module designed for VersaMax PLC systems. It controls external DC loads by switching output signals from the PLC controller.
Q2: How many output channels does the IC200MDL750B provide?
A: The module provides 32 discrete output points arranged in two groups of 16 outputs, allowing flexible connection of multiple DC devices.
Q3: What type of output does the IC200MDL750B use?
A: The module uses positive logic sourcing outputs, which provide current to connected field devices when the output is activated.
Q4: What voltage range is supported by the IC200MDL750B?
A: The module supports external field power from +10.2 to +30 VDC and is commonly used with 12 VDC or 24 VDC industrial control systems.
Q5: What is the maximum load current for each output point?
A: Each output point supports up to 0.5 A at 30 VDC resistive load, making it suitable for controlling various industrial DC devices.
Q6: Does the IC200MDL750B provide output status monitoring?
A: Yes. Each output channel includes an LED indicator to display output status, helping users monitor operation and troubleshoot wiring issues.
Q7: What should be considered when wiring the IC200MDL750B?
A: Verify DC power polarity, output load current, group power connections, and use suitable protection measures when controlling inductive loads such as relays or solenoids.
Q8: What should be checked when replacing an IC200MDL750B module?
A: Confirm VersaMax system compatibility, output voltage requirements, field power capacity, terminal wiring, load specifications, and PLC configuration settings before replacement.
GE Fanuc IC200MDL750B Discrete DC Output Module is in stock. Please contact us for a quick quote and competitive pricing.
