GE Fanuc IC200MDL930A Relay Output Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC200MDL930A |
| Manufacturer | GE Fanuc |
| Product Series | VersaMax Distributed I/O |
| Product Type | Relay Output Module |
| Main Function | Provides isolated relay switching outputs for controlling AC and DC field devices in VersaMax I/O systems |
| Application | Industrial automation, machine control, motor control, solenoid control, alarms, and process equipment |
| Output Type | Isolated Form A relay outputs |
| Number of Outputs | 8 output points |
| Output Configuration | Individually isolated normally open (N.O.) relay contacts |
| Relay Type | Fixed coil, moving armature |
| Contact Type | Silver alloy contact |
| Rated Output Voltage | 5/24/125 VDC; 120/240 VAC |
| Output Voltage Range | 0 to 125 VDC; 0 to 265 VAC (47–63 Hz) |
| Output Current Rating | 2.0 A maximum per point (resistive load) |
| DC Load Rating | 2.0 A maximum at 5–30 VDC; 0.2 A maximum at 31–125 VDC |
| Minimum Load Current | 10 mA per point |
| Output Response Time | 10 ms maximum ON; 10 ms maximum OFF |
| Switching Frequency | 20 cycles/minute maximum for inductive loads |
| Output Isolation | Point-to-point isolated relay outputs |
| Isolation Rating | 250 VAC continuous; 1500 VAC for 1 minute |
| Output Leakage Current | None (open relay contact) |
| Protection | No internal fuses or snubbers |
| LED Indicators | Individual green LEDs for each output point status; OK LED indicates backplane power |
| External Power Supply | Field load power supplied externally |
| Backplane Power Consumption | Approximately 245 mA maximum at 5 VDC |
| Terminal Connection | VersaMax terminal carrier interface |
| Mounting Type | VersaMax base/carrier mounted module |
| Intelligent Processing | Managed by CPU or Network Interface Unit |
| Output Data | Receives 8-bit discrete output data |
| Hazardous Location Support | Suitable for specified industrial Class I Division 2 applications |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | Approximately 50 mm × 110 mm × 66.8 mm |
| Weight | Approximately 0.26 kg |
| Compatibility | GE Fanuc VersaMax PLC and distributed I/O systems |
FAQ
Q1: What is the main function of the IC200MDL930A?
A: The IC200MDL930A is a VersaMax relay output module that provides eight individually isolated Form A relay outputs for switching external AC and DC loads.
Q2: How many output channels does the IC200MDL930A provide?
A: The module provides 8 isolated relay output points.
Q3: What types of loads can the IC200MDL930A control?
A: It can control AC and DC loads, including contactors, solenoids, motor starters, indicators, alarms, and other industrial field devices within the rated voltage and current limits.
Q4: What voltage ranges are supported by the IC200MDL930A?
A: The module supports 0–125 VDC and 0–265 VAC output applications, including common 24 VDC, 120 VAC, and 240 VAC systems.
Q5: What is the advantage of isolated relay outputs?
A: Individual isolation allows separate field circuits to be controlled independently and helps reduce electrical interference between output channels.
Q6: What should be checked before replacing an IC200MDL930A module?
A: Verify VersaMax system compatibility, output wiring, load voltage, relay ratings, field power supply, terminal connections, and PLC configuration before replacement.
Q7: What factors may affect IC200MDL930A performance?
A: Excessive switching frequency, overloaded relay contacts, unstable field power, incorrect wiring, electrical noise, and poor environmental conditions may reduce relay reliability.
Q8: How can the reliability of the IC200MDL930A be maintained?
A: Regular inspection of wiring terminals, checking load current, maintaining proper cabinet conditions, ensuring stable power supply, and performing periodic system diagnostics can improve long-term reliability.
GE Fanuc IC200MDL930A Relay Output Module is in stock. Please contact us for a quick quote and competitive pricing.
