Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC694MDL930CA |
| Manufacturer | GE Fanuc / Emerson |
| Product Series | PACSystems RX3i / Series 90-30 Compatible I/O |
| Product Type | Isolated Relay Output Module |
| Main Function | Provides relay-based discrete output switching for controlling external AC and DC field devices |
| Application | Industrial automation, machine control, motor control, solenoid control, indicator control, and process systems |
| Output Type | Normally Open (N.O.) relay outputs |
| Number of Outputs | 8 isolated relay output points |
| Output Configuration | Individually isolated Form A relay contacts |
| Rated Voltage | 24 VDC, 120 VAC, 240 VAC |
| Operating Voltage Range | 5 to 30 VDC; 5 to 250 VAC |
| Output Current Rating | 4 A maximum resistive load per point |
| Pilot Duty Current | 2 A maximum per point |
| Frequency Range | 50/60 Hz for AC loads |
| Isolation Type | Point-to-point and field-to-backplane isolation |
| Isolation Rating | 250 VAC continuous; 1500 VAC for 1 minute dielectric withstand |
| Minimum Load Current | 10 mA |
| Maximum Inrush Current | 5 A |
| Relay Response Time | Approximately 15 ms maximum ON/OFF response |
| Contact Type | Mechanical relay contact |
| Output Protection | Relay isolation design for mixed voltage applications |
| LED Indicators | Individual output status LEDs |
| External Power Requirement | User-supplied field power for connected devices |
| Backplane Power Consumption | Approximately 6 mA from 5 VDC bus and 70 mA from 24 V relay bus |
| Terminal Connection | Screw terminal interface |
| Mounting Type | PLC rack-mounted I/O module |
| Installation Position | Any available I/O slot in compatible RX3i system |
| Hot Swap Support | Supported according to system configuration requirements |
| Module Design | Conformal coated industrial version |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | Approximately 145 mm × 34 mm × 140 mm |
| Weight | Approximately 0.38 kg |
| Compatibility | GE Fanuc / Emerson PACSystems RX3i and compatible Series 90-30 control platforms |
FAQ
Q1: What is the main function of the IC694MDL930CA?
A: The IC694MDL930CA is an isolated relay output module designed to switch external AC or DC loads and provide reliable interface control between PLC systems and field devices.
Q2: How many output channels does the IC694MDL930CA provide?
A: The module provides eight individually isolated normally open relay output channels for flexible field device control.
Q3: What types of loads can be controlled by the IC694MDL930CA?
A: The module can control various industrial loads including motor starters, solenoids, contactors, alarms, indicators, and other AC/DC field devices.
Q4: What voltage ranges are supported by the IC694MDL930CA?
A: The module supports 5–30 VDC and 5–250 VAC switching applications, including common 24 VDC, 120 VAC, and 240 VAC systems.
Q5: What is the advantage of isolated relay outputs in the IC694MDL930CA?
A: Individual isolation between output points helps prevent electrical interference between different field circuits and allows mixed voltage applications within the same module.
Q6: What should be checked before replacing an IC694MDL930CA module?
A: Users should verify PLC rack compatibility, output wiring, load voltage requirements, relay configuration, field power supply conditions, and system parameters before replacement.
Q7: What factors may affect the performance of the IC694MDL930CA?
A: Excessive load current, frequent switching, unstable field power, incorrect wiring, electrical noise, and unsuitable environmental conditions may reduce relay service life or reliability.
Q8: How can the reliability of the IC694MDL930CA be maintained?
A: Regular inspection of terminal connections, verification of load ratings, proper cabinet ventilation, stable power conditions, and periodic system diagnostics help maintain reliable long-term operation.
