GE Fanuc IC695CMM004CA Conformal Coated Serial Communication Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC695CMM004CA |
| Manufacturer | GE Fanuc / Emerson |
| Product Series | PACSystems RX3i |
| Product Type | Conformal Coated Serial Communication Module |
| Main Function | Provides multiple isolated serial communication channels for connecting external devices and serial networks to PACSystems RX3i controllers |
| Application | Industrial automation, SCADA systems, process control, distributed control systems, and equipment communication |
| Communication Ports | 4 independent isolated serial ports |
| Port Type | Software-configurable RS-232 / RS-485 / RS-422 |
| Communication Mode | Full duplex and half duplex operation support |
| Supported Protocols | Modbus Master, Modbus Slave, CCM Slave, DNP3 Master, DNP3 Slave, and Serial I/O protocols |
| Connector Type | RJ-45 serial connectors |
| Baud Rate Range | 1200 to 115.2 kbps |
| Data Format | Selectable 7 or 8 data bits, 1 or 2 stop bits |
| Parity Support | None, Even, Odd |
| RS-232 Flow Control | RTS/CTS and RFR/CTS hardware handshake support |
| RS-485/422 Mode | Supports 2-wire half duplex and 4-wire full duplex communication |
| Port Isolation | Port-to-port and port-to-backplane isolation |
| Isolation Rating | 250 VAC continuous port-to-backplane isolation; 1500 VAC for 1 minute |
| Overvoltage Protection | ±25 V maximum input protection |
| Module Capacity | Up to 6 serial communication modules in the main RX3i backplane |
| Backplane Interface | PACSystems RX3i universal backplane |
| Slot Requirement | 1 single slot |
| Configuration Software | Proficy Machine Edition / PAC Machine Edition |
| Firmware Upgrade | Field-upgradable firmware support |
| Diagnostic Features | Module fault reporting, communication status monitoring, port diagnostics |
| LED Indicators | Module OK, port status, and port fault indicators |
| Conformal Coating | Yes, enhanced protection for harsh industrial environments |
| Power Supply | 3.3 VDC and 5 VDC backplane power |
| Power Consumption | Approximately 0.7 A at 3.3 VDC and 0.15 A at 5 VDC |
| Mounting Type | RX3i rack-mounted module installation |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | Approximately 130 mm × 35 mm × 140 mm |
| Weight | Approximately 0.3 kg |
| Compatibility | GE Fanuc / Emerson PACSystems RX3i control platforms |
FAQ
Q1: What is the main function of the IC695CMM004CA?
A: The IC695CMM004CA is a PACSystems RX3i serial communication module designed to provide four independent isolated serial interfaces for communication with external devices and industrial networks.
Q2: How many communication ports does the IC695CMM004CA provide?
A: The module provides four independent isolated serial communication ports that can be configured according to system requirements.
Q3: Which communication protocols are supported by the IC695CMM004CA?
A: The module supports Modbus Master, Modbus Slave, CCM Slave, DNP3 Master, DNP3 Slave, and Serial I/O communication protocols.
Q4: What serial interfaces are available on the IC695CMM004CA?
A: Each port can be configured for RS-232, RS-485, or RS-422 communication, allowing connection with a wide range of industrial devices.
Q5: What is the difference between IC695CMM004CA and IC695CMM004?
A: The IC695CMM004CA is the conformal-coated version of the standard IC695CMM004 module, providing improved resistance against moisture, dust, and industrial environmental conditions.
Q6: What should be checked before replacing an IC695CMM004CA module?
A: Users should verify RX3i backplane compatibility, communication protocol settings, serial wiring configuration, firmware version, power supply conditions, and device addressing before replacement.
Q7: What factors may affect the performance of the IC695CMM004CA?
A: Incorrect serial wiring, baud rate mismatch, grounding issues, electrical interference, unstable power supply, and incorrect protocol configuration may affect communication reliability.
Q8: How can the reliability of the IC695CMM004CA be maintained?
A: Regular inspection of communication cables, proper grounding, stable rack power, firmware management, environmental protection, and periodic diagnostic checks help maintain reliable long-term operation.
GE Fanuc IC695CMM004CA Conformal Coated Serial Communication Module is in stock. Please contact us for a quick quote and competitive pricing.
