GE Fanuc IC695PNC001CA PROFINET Controller Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC695PNC001CA |
| Manufacturer | GE Fanuc / Emerson |
| Product Series | PACSystems RX3i |
| Product Type | PROFINET Controller Module |
| Main Function | Connects PACSystems RX3i controllers to PROFINET networks and manages communication with PROFINET I/O devices |
| Application | Industrial automation, distributed I/O control, machine automation, and process control systems |
| PROFINET Support | PROFINET Version 2.2 General Class A I/O Controller |
| Redundancy Support | Supports PROFINET Type S-2 system redundancy operation |
| Communication Interface | Industrial Ethernet PROFINET communication |
| Ethernet Ports | 4 switched Ethernet ports |
| Copper Ports | 2 × RJ-45 shielded twisted-pair ports |
| Fiber Ports | 2 × SFP module ports |
| Ethernet Speed | 10/100/1000 Mbps copper; 100/1000 Mbps fiber depending on SFP module type |
| Fiber Support | Supports multimode and single-mode fiber through compatible SFP devices |
| Network Topology | Supports star, line, daisy-chain, and ring network configurations |
| Media Redundancy | Supports Media Redundancy Protocol (MRP) |
| Maximum I/O Memory | Up to 128 KB combined PROFINET input/output memory |
| CPU Compatibility | Compatible with PACSystems RX3i CPUs including CPU315, CPU320, and supported higher-performance controllers |
| Configuration Software | Proficy Machine Edition / PAC Machine Edition |
| Configuration Function | Provides PROFINET controller configuration, scanner configuration, and third-party I/O device setup |
| Service Interface | Micro USB port for system setup, diagnostics, and command-line access |
| Firmware Update | Supports firmware upgrade through engineering tools |
| Diagnostic Features | Network status monitoring, module diagnostics, communication fault detection, and event logging |
| LED Indicators | OK, LAN, STATUS, CONFIG, ACTIVE, USB, and port status indicators |
| Clock Function | Internal clock synchronization with RX3i CPU for timestamped diagnostic records |
| Mounting Type | RX3i universal backplane installation |
| Slot Requirement | 1 single backplane slot |
| Backplane Interface | RX3i universal backplane communication |
| Power Supply | 3.3 VDC and 5 VDC backplane power |
| Power Consumption | 3.3 VDC: approximately 0.5 A without SFP modules; up to 1.2 A with two SFP modules; 5 VDC: approximately 1.5 A maximum |
| Conformal Coating | Yes, CA version provides enhanced environmental protection |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | Approximately 130 mm × 35 mm × 140 mm |
| Weight | Approximately 0.3 kg |
| Compatibility | GE Fanuc / Emerson PACSystems RX3i control platforms |
FAQ
Q1: What is the main function of the IC695PNC001CA?
A: The IC695PNC001CA is a PACSystems RX3i PROFINET Controller module used to connect an RX3i controller to PROFINET networks and exchange data with distributed PROFINET I/O devices.
Q2: What type of communication protocol does the IC695PNC001CA support?
A: The module supports PROFINET communication and functions as a PROFINET I/O Controller for managing connected PROFINET devices.
Q3: How many Ethernet ports does the IC695PNC001CA provide?
A: The module provides four switched Ethernet ports, including two RJ-45 copper ports and two SFP ports for flexible network configurations.
Q4: Can the IC695PNC001CA support fiber optic communication?
A: Yes. The module supports fiber communication through compatible SFP modules, including multimode and single-mode fiber solutions.
Q5: What network topologies are supported by the IC695PNC001CA?
A: The module supports star, line, daisy-chain, and ring network structures with Media Redundancy Protocol support for improved network availability.
Q6: What should be checked before replacing an IC695PNC001CA module?
A: Users should verify RX3i backplane compatibility, PROFINET configuration, IP settings, firmware version, SFP module selection, network topology, and power supply conditions before replacement.
Q7: What factors may affect the performance of the IC695PNC001CA?
A: Incorrect PROFINET configuration, damaged Ethernet cables, incompatible SFP modules, unstable backplane power, firmware mismatches, and network interference may affect communication performance.
Q8: How can the reliability of the IC695PNC001CA be maintained?
A: Regular network inspections, proper cabinet installation, firmware management, stable power supply, backup of configuration data, and periodic diagnostic checks help maintain reliable long-term operation.
GE Fanuc IC695PNC001CA PROFINET Controller Module is in stock. Please contact us for a quick quote and competitive pricing.
