Ovation 5X00105G01 9700931-0002A Control Circuit Board
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 5X00105G01 |
| Ordering Number | 9700931-0002A |
| Product Type | Control Circuit Board |
| Product Series | Ovation |
| System | Emerson Ovation DCS |
| Board Function | Ovation Controller Control Board |
| Controller Architecture | OCR161 Controller |
| Processor | 266 MHz |
| RAM | 32 MB |
| Flash Memory | 32 MB |
| Mounting Type | Chassis / Backplane Mounted |
| Communication | Ovation Controller System Interface |
| Application | Distributed Control System, Process Control, Power Generation |
| Real-Time Processing | Supported |
| Control Logic Execution | Supported |
| System Diagnostics | Supported |
| Redundancy Application | Supported in compatible Ovation controller configurations |
| Operating Temperature | 0–60 °C |
| Installation Environment | Industrial control cabinet |
| ESD Protection | Required during installation and handling |
| Product Status | Discontinued |
| Dimensions | 250 × 120 × 50 mm |
| Weight | 0.277 kg |
FAQ
1. What is the main function of the Ovation 5X00105G01 control circuit board?
The 5X00105G01 is an Ovation control board used in the controller architecture of the Emerson Ovation DCS. It provides the processing resources required for executing control logic, managing system data, and communicating with other components of the control system.
2. What controller is associated with the 5X00105G01?
The 5X00105G01 is associated with the OCR161 controller architecture. Technical information for the OCR161 identifies the 5X00105G01 as a 266 MHz controller card with 32 MB RAM and 32 MB flash memory.
3. What is the ordering number for the 5X00105G01?
The model is 5X00105G01, while the specified ordering number is 9700931-0002A. These identifiers should be checked against the existing board and system documentation before ordering a replacement.
4. What are the memory specifications of the 5X00105G01?
The 5X00105G01 configuration associated with the OCR161 controller uses 32 MB of RAM and 32 MB of flash memory. The RAM supports controller runtime operations, while flash memory provides non-volatile storage for system-related software or data.
5. How should the 5X00105G01 be installed?
The board should be installed in the correct Ovation controller chassis or backplane position specified by the system configuration. System power should be removed before inserting or removing the board, and appropriate ESD precautions should be followed to protect the PCB and backplane connections.
6. What should be checked if the Ovation controller does not start after installing the 5X00105G01?
Check that the board is fully seated, the backplane connector is clean and undamaged, and the controller power supply is operating normally. Also verify that the installed board revision is compatible with the controller configuration and check available system diagnostics for processor, memory, or communication faults.
7. What are common causes of communication problems involving the 5X00105G01?
Communication problems can result from an improperly seated board, damaged backplane connections, incorrect controller configuration, incompatible hardware revisions, or problems with connected communication interfaces. Diagnostic indicators and system logs should be checked before replacing the board.
8. Is the Ovation 5X00105G01 still available as a current production board?
The 5X00105G01 is listed as discontinued. For an existing Ovation system, replacement selection should consider the controller generation, board revision, firmware/software compatibility, memory configuration, and the complete system architecture rather than matching the model number alone.
Ovation 5X00105G01 9700931-0002A Control Circuit Board is in stock. Please contact us for a quick quote and competitive pricing.
