Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | ATV610U40N4 |
| Manufacturer | Schneider Electric |
| Product Type | Variable Speed Drive (VFD) |
| Product Series | Easy Altivar 610 |
| Drive Type | AC Variable Frequency Drive |
| Motor Compatibility | 3-Phase Asynchronous and Synchronous Motors |
| Rated Motor Power (Normal Duty) | 4.0 kW (5 HP) |
| Rated Motor Power (Heavy Duty) | 3.0 kW (4 HP) |
| Supply Voltage | 380–460V AC (-15%/+10%) |
| Supply Phases | 3-Phase |
| Supply Frequency | 50/60 Hz ±5% |
| Line Current | 11.5 A @ 380V (Normal Duty) |
| Continuous Output Current | 9.5 A @ 4 kHz (Normal Duty) |
| Maximum Transient Current | 10.5 A for 60 s |
| Output Frequency Range | 0.1–500 Hz |
| Switching Frequency | 2–12 kHz Adjustable |
| Nominal Switching Frequency | 4 kHz |
| Motor Control Modes | Constant Torque, Variable Torque, Optimized Torque |
| Communication Protocol | Modbus Serial (RS-485) |
| Communication Port | RJ45 |
| Digital Inputs | 6 |
| Digital Outputs | 3 |
| Analog Inputs | 3 |
| Analog Outputs | 2 |
| Relay Outputs | 3 |
| EMC Filter | Integrated EMC Filter (Category C3) |
| Protection Rating | IP20 |
| Cooling Method | Forced Convection |
| Mounting Type | Cabinet / Panel Mount |
| Operating Temperature | -15°C to 45°C (up to 60°C with derating) |
| Storage Temperature | -40°C to 70°C |
| Operating Altitude | Up to 1000 m without derating |
| Dimensions (H × W × D) | 297 × 145 × 203 mm |
| Weight | 2.8 kg |
| Typical Applications | Fans, Pumps, Compressors, Conveyors |
| Lifecycle Status | Active Product |
FAQ
Q1: What is the ATV610U40N4 used for?
A1: It is a variable frequency drive designed for controlling industrial motors in pump, fan, compressor, and conveyor applications.
Q2: What motor size can it control?
A2: It supports 4.0 kW (5 HP) motors in normal-duty applications and 3.0 kW (4 HP) motors in heavy-duty applications.
Q3: Which communication protocol is built in?
A3: The drive includes Modbus Serial communication via an RS-485 interface with an RJ45 connector.
Q4: How many I/O points are available?
A4: It provides 6 digital inputs, 3 digital outputs, 3 analog inputs, 2 analog outputs, and 3 relay outputs.
Q5: What protection features are included?
A5: The drive includes overload, overcurrent, short-circuit, overvoltage, undervoltage, motor thermal protection, and phase-loss protection.
Q6: What are the dimensions and weight?
A6: The unit measures 297 × 145 × 203 mm and weighs approximately 2.8 kg.
Q7: What environmental conditions can it operate in?
A7: It operates from -15°C to 45°C without derating and up to 60°C with derating. Installation is supported up to 1000 m altitude without derating.
Q8: Is the ATV610U40N4 still available?
A8: Yes, it remains an active member of the Schneider Electric Easy Altivar 610 drive family.
