Schneider BMXFCC301 Cable Assemblies
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Type | Cable Assembly |
| Model | BMXFCC301 |
| Product Range | Modicon X80 |
| Application | Modicon M340 I/O system |
| Accessory Type | Preformed cordset for Telefast ABE7 sub-base |
| Intended For | I/O modules with 40-way connectors |
| Electrical Connection | 1 × 40-way connector + 1 × HE10 connector |
| Number of Cables | 1 |
| Total Number of Wires | 20 |
| Wire Cross-Section | 0.324 mm² |
| Cable Length | 3 m |
| Connection Type | 40-way I/O connection to HE10 interface |
| Main Function | Provides a preassembled connection between compatible Modicon X80 I/O modules and Telefast ABE7 interface equipment |
| Installation | Plug-in connection for industrial control and I/O wiring |
| Signal Application | Primarily intended for compatible discrete I/O connections |
| Wiring Configuration | Preassembled and factory-terminated |
| Maintenance | Check connectors, cable insulation, terminals, and mechanical condition regularly |
| Replacement Requirement | Verify model number, connector configuration, cable length, and I/O compatibility before replacement |
| Weight | 0.84 kg |
FAQ
1. What is the Schneider BMXFCC301 Cable Assembly?
The BMXFCC301 is a preformed cable assembly from the Schneider Electric Modicon X80 range. It is designed to connect compatible 40-way I/O modules with Telefast ABE7 interface equipment. The factory-assembled connectors simplify field wiring and reduce manual termination work during installation.
2. Which Schneider Electric systems can use the BMXFCC301?
The BMXFCC301 is intended for compatible Modicon X80 I/O applications, particularly M340 I/O modules using a 40-way connection. It is also designed for connection to Telefast ABE7 sub-bases through its HE10 connector. The exact module and interface should be checked against the control system wiring configuration before installation.
3. What connectors are provided on the BMXFCC301?
The cable assembly uses one 40-way connector and one HE10 connector. This configuration provides a preassembled interface between the applicable I/O module and the Telefast ABE7 side. Correct connector orientation and full engagement should be verified during installation to prevent intermittent I/O signals.
4. What is the purpose of the BMXFCC301 in an industrial control system?
Its main purpose is to provide an organized electrical connection between a compatible Modicon I/O module and an ABE7 interface system. Using a preformed cordset simplifies panel wiring and reduces individual wire termination work. It also helps maintain a consistent connection arrangement when multiple I/O channels are installed.
5. Can the BMXFCC301 be used with any 40-way PLC I/O module?
No. Having a 40-way connector alone does not guarantee compatibility. The module’s electrical pin assignment, connector type, signal arrangement, and corresponding ABE7 interface must all match the cable configuration. The BMXFCC301 should therefore be selected according to the specific Schneider Electric I/O module and wiring architecture.
6. What should be checked if I/O signals are missing when using the BMXFCC301?
First check that both connectors are fully inserted and correctly locked into their respective interfaces. Then inspect the cable for damaged insulation, excessive bending, crushed sections, or loose connector contacts. If the physical connection is correct, check the I/O module configuration, channel assignment, terminal wiring, and associated ABE7 interface.
7. Is the BMXFCC301 suitable for extending another cable?
The BMXFCC301 is designed as a complete preformed connection cable rather than as a general-purpose extension lead. Adding an unapproved extension or modifying the factory-terminated wiring can change the intended pin configuration and introduce additional connection points. If a longer connection is required, the appropriate Schneider Electric cable variant should be selected.
8. What maintenance is recommended for the BMXFCC301?
Routine maintenance should focus on the connectors, cable insulation, and mechanical routing of the assembly. Check for loose connections, damaged insulation, excessive bending, abrasion, contamination, or signs of overheating. When replacing the cable, verify the BMXFCC301 model and connector configuration before installation to ensure that the original I/O wiring arrangement is maintained.
Schneider BMXFCC301 Cable Assemblies is in stock. Please contact us for a quick quote and competitive pricing.
