Technical Specifications
| Parameter | Description |
|---|---|
| Brand | Schneider Electric |
| Model | HMIG3U |
| Product Name | Universal Panel Advanced Box |
| Product Series | Harmony GTU |
| Product Type | HMI Processing Unit |
| Processor | RISC CPU, 600 MHz |
| Operating System | Harmony |
| Runtime Software | Vijeo Designer Runtime |
| Rated Supply Voltage | 12–24 V DC |
| RAM | 256 MB |
| Non-Volatile Memory | 512 KB NVRAM |
| Storage | 1 GB SD card |
| SD Card Slots | 2 |
| Ethernet Interfaces | 2 × RJ45 Ethernet ports |
| Serial Interface COM1 | RJ45, RS-485 |
| Serial Interface COM2 | 9-pin SUB-D, supporting RS-232C, RS-422, and RS-485 |
| USB Interfaces | 2 × USB 2.0 Type-A, 1 × USB Mini-B |
| Additional Interfaces | Auxiliary terminal interface and expansion fieldbus card interface |
| Supported Communication Protocols | Modbus, Modbus TCP/IP, Uni-Telway |
| Compatible Product Series | Compatible Harmony GTU display modules |
| Status Indicators | Multicolor LED status indicators |
| Cooling Method | Natural convection |
| Dimensions | 188 × 45 × 131 mm |
| Weight | 0.9 kg |
| Typical Applications | Industrial HMI systems, PLC communication, machine operation, equipment monitoring, and process visualization |
FAQ
Q1: What is the main function of the Schneider HMIG3U Universal Panel Advanced Box?
A: The HMIG3U serves as the processing and communication unit in a modular Harmony GTU HMI system. When paired with a compatible display module, it supports operator interaction, equipment status monitoring, alarm handling, and process visualization.
Q2: Which display modules are compatible with the HMIG3U?
A: The HMIG3U is designed for compatible Harmony GTU display modules. Compatibility should be verified against the exact display model and the manufacturer’s hardware documentation before installation.
Q3: Which communication interfaces are available on the HMIG3U?
A: The unit provides Ethernet, serial communication, and USB interfaces. The available connections support integration with compatible PLCs, industrial controllers, and peripheral devices, depending on the selected communication method.
Q4: Can the HMIG3U communicate with PLCs from different manufacturers?
A: Communication is possible when the PLC supports a compatible protocol and interface. Modbus and Modbus TCP/IP are commonly used for industrial controller integration. Correct addressing, communication parameters, and driver configuration are essential for reliable data exchange.
Q5: How can communication faults between the HMIG3U and a PLC be diagnosed?
A: Check the communication cable, interface selection, PLC address, protocol settings, and serial parameters where applicable. For Ethernet connections, verify the IP addresses and network connectivity. Reviewing diagnostic messages from both devices can help identify the cause.
Q6: What are the SD card slots used for?
A: Compatible SD cards may be used for supported storage and data-handling functions, depending on the system configuration. Confirm the supported card specifications and intended functions in the applicable technical documentation before using removable storage.
Q7: Which software is used to configure the HMIG3U?
A: The HMIG3U is associated with Vijeo Designer Runtime for executing HMI applications. The compatible engineering software version should be confirmed before developing, transferring, or modifying a project.
Q8: What maintenance practices help keep the HMIG3U operating reliably?
A: Inspect power and communication connections regularly, keep the unit clean and dry, and maintain adequate airflow around the enclosure. Back up application files and configuration data before performing maintenance, updating software, or replacing hardware.
Schneider HMIG3U Universal Panel Advanced Box is in stock. Please contact us for a quick quote and competitive pricing.
