Siemens 6AG1226-6BA32-5XB0 VDC Logic I/O Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Model |
|
|
Brand |
|
|
Product Series |
SIPLUS S7-1200 SM 1226 |
|
Product Type |
Fail-Safe Digital Input Module |
|
Base Model |
6ES7226-6BA32-0XB0 |
|
Number of Digital Inputs |
16 |
|
Input Voltage |
24 V DC |
|
Permissible Supply Voltage Range |
20.4–28.8 V DC |
|
Input Signal “0” |
-30 to +5 V DC |
|
Input Signal “1” |
15 to 30 V DC |
|
Typical Input Current |
5 mA per input at signal “1” |
|
Maximum Input Current from Sensor Supply |
130 mA, excluding input and sensor-supply loads |
|
Backplane Bus Current Consumption |
Maximum 155 mA at 5 V DC |
|
Typical Power Dissipation |
7 W |
|
Input Delay |
Configurable: 0.8, 1.6, 3.2, 6.4 or 12.8 ms |
|
Maximum Cable Length |
Up to 200 m, subject to input filter and cable-shielding requirements |
|
Safety Communication |
PROFIsafe |
|
Safety Performance |
Up to PL e and SIL 3, depending on system configuration |
|
Diagnostic Functions |
Input status LEDs and diagnostic information |
|
Protection Rating |
IP20 |
|
Protective Coating |
Conformal coating |
|
Operating Temperature Range |
-25°C to +55°C |
|
Compatible Controller |
Siemens SIMATIC S7-1200 |
|
Dimensions |
107 × 87 × 84 mm |
|
Weight |
0.239 kg |
FAQ
1. What is the Siemens 6AG1226-6BA32-5XB0 used for?
The 6AG1226-6BA32-5XB0 is a SIPLUS S7-1200 SM 1226 fail-safe digital input module. It acquires safety-related 24 V DC signals from devices such as safety switches and sensors for use in industrial automation and machine safety systems.
2. How many digital inputs does this module provide?
The module provides 16 fail-safe digital inputs. Depending on the safety configuration, the inputs can be used as 16 single-channel inputs or configured as eight two-channel input pairs.
3. Does the module support PROFIsafe communication?
Yes. It supports PROFIsafe for transmitting safety-related input information within a compatible safety automation system. The CPU, network configuration, and safety program must also support the selected PROFIsafe configuration.
4. What safety performance level can be achieved?
The module can support up to Performance Level e (PL e) under ISO 13849-1 and SIL 3 under IEC 61508 in suitable two-channel configurations. The achieved safety level depends on the complete system design, wiring, safety logic, and validation.
5. What input voltage levels are recognized as digital signals?
The input signal “0” range is -30 to +5 V DC, while the signal “1” range is 15 to 30 V DC. Signals between these ranges should not be treated as valid logic states without checking the applicable operating conditions.
6. Can the input response time be configured?
Yes. The input delay can be configured to 0.8, 1.6, 3.2, 6.4, or 12.8 ms. The selected delay affects signal filtering and response time, so it should be chosen according to the sensor characteristics and safety application requirements.
7. What diagnostic functions are available?
The module provides input-status LED indication and diagnostic information. During troubleshooting, check the status indicators, sensor supply, wiring, input voltage levels, and diagnostic messages in the engineering environment.
8. What should be checked before commissioning the module?
Confirm compatibility with the SIMATIC S7-1200 CPU, verify the 24 V DC supply, configure the safety inputs and PROFIsafe parameters, and inspect the wiring and grounding. Complete the required safety validation and functional tests before putting the machine into operation.
Siemens 6AG1226-6BA32-5XB0 VDC Logic I/O Module is in stock. Please contact us for a quick quote and competitive pricing.
