Siemens 6AG1307-1EA01-7AA0 VDC Logic I/O Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | 6AG1307-1EA01-7AA0 |
| Brand | Siemens |
| Product Type | SIPLUS S7-300 PS 307 Power Supply Module |
| Base Model | 6ES7307-1EA01-0AA0 |
| Product Series | SIPLUS S7-300 |
| Power Supply Type | Single-phase AC/DC power supply |
| Input Voltage | 120/230 V AC |
| Permissible Input Voltage Range | 85–132 V AC / 170–264 V AC |
| Input Frequency | 47–63 Hz |
| Output Voltage | 24 V DC |
| Rated Output Current | 5 A |
| Output Power | 120 W |
| Output Voltage Tolerance Range | 23.27–24.72 V DC |
| Typical Input Current at 120 V AC | 2.3 A |
| Typical Input Current at 230 V AC | 1.2 A |
| Maximum Inrush Current | 20 A |
| Power Failure Buffering | Minimum 20 ms at rated output current |
| Overvoltage Protection | Electronic protection with automatic restart |
| Short-Circuit Protection | Electronic shutdown with automatic restart |
| Typical Residual Ripple | 10 mV peak-to-peak |
| Maximum Residual Ripple | 50 mV peak-to-peak |
| Operating Temperature | -25°C to +70°C |
| Output Current Above 60°C | Up to 3 A |
| Environmental Protection | Conformal coating on printed circuit boards and electronic components |
| Mounting Method | Direct mounting on the S7-300 DIN rail |
| Diagnostic Indicator | LED for 24 V DC output status |
| Dimensions | 170 × 130 × 67 mm |
| Weight | 0.563 kg |
| Typical Applications | PLC power supply, industrial automation, control cabinets, and S7-300 system power distribution |
FAQ
Q1: What is the main function of the Siemens 6AG1307-1EA01-7AA0?
A: The Siemens 6AG1307-1EA01-7AA0 is a SIPLUS S7-300 PS 307 power supply module. It converts 120/230 V AC input power into a regulated 24 V DC output to supply the PLC, compatible I/O modules, sensors, actuators, and other control system components.
Q2: What input voltage range does this power supply support?
A: The module supports two AC input ranges: 85–132 V AC and 170–264 V AC. It can operate on compatible 120 V or 230 V AC single-phase networks. Confirm the supply voltage and wiring before energizing the unit.
Q3: What are the rated output voltage and current?
A: The rated output is 24 V DC at 5 A, providing up to 120 W of output power under the specified operating conditions. When the ambient temperature exceeds 60°C, the available output current is limited to 3 A.
Q4: Can the 6AG1307-1EA01-7AA0 power an entire S7-300 PLC system?
A: It can supply compatible S7-300 system components, including the CPU and I/O modules, provided the total current demand remains within the power supply’s rated capacity. Calculate the combined load of all connected devices and allow sufficient margin for startup currents and future expansion.
Q5: What protection functions are available on this power supply?
A: The module includes overvoltage protection and electronic short-circuit protection. Under the specified conditions, the protection circuitry can automatically restart after a fault. The cause of repeated shutdowns should be identified before the system is returned to normal operation.
Q6: What should be checked if the 24 V DC output is missing or unstable?
A: Check the AC input voltage, input wiring, protective devices, and output connections first. Then disconnect the downstream load where appropriate and verify whether the power supply can produce the correct output under a controlled test. A short circuit, excessive load, loose terminal, or internal failure may cause abnormal output behavior.
Q7: What installation precautions are important for this SIPLUS power supply?
A: Mount the unit securely on the compatible S7-300 DIN rail and follow the wiring and terminal requirements in the product documentation. Ensure adequate ventilation, correct AC input selection, reliable protective grounding, and secure connections. Disconnect the power before installation or maintenance, and observe electrical safety procedures.
Q8: What should be considered when replacing this module in an existing PLC system?
A: Verify the complete order number, input voltage requirements, 24 V DC output rating, mounting compatibility, and environmental requirements before replacement. This model is based on the standard 6ES7307-1EA01-0AA0 design and features conformal coating for extended environmental conditions. After installation, check the 24 V DC output, confirm that the connected PLC components start normally, and monitor the system for alarms or abnormal voltage fluctuations.
