Siemens 6AG4114-3HE13-4BX1 Rack-Mount Industrial Computer

  • Manufacturer: Siemens
  • Product Number: 6AG4114-3HE13-4BX1
  • Condition: New & In Stock
  • Product Type: Rack-Mount Industrial Computer
  • Origin: Germany
  • Payment Methods: T/T, Western Union
  • Dimensions: 444 × 430 × 177 mm
  • Weight: 17 kg
  • Shipping Port: Xiamen, China
  • Lead Time: 1-3 Working Days
  • Warranty: One Year
  • Certificate: COO
  • Courier partners: DHL, UPS, TNT, FedEx and EMS.

Product Detail

Contact Us

FAQS

Packing & Delivery

Company Information
e-mail [email protected]
Mobile +8613666084105
Whatsapp +8613666084105
WeChat 15305023276
Add to Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Technical Specifications

Parameter Specification
Brand Siemens
Model 6AG4114-3HE13-4BX1
Product Series SIMATIC IPC847E
Product Type Rack-Mount Industrial Computer
Design 19-inch, 4U Rack PC
Mounting Rack mounting; suitable for horizontal and vertical installation; prepared for telescopic rails
Processor Intel Core i7-8700
Processor Cores / Threads 6 Cores / 12 Threads
Base Frequency 3.2 GHz
Max. Turbo Frequency 4.6 GHz
Processor Cache 12 MB
Chipset Intel C246
Installed Memory 32 GB DDR4 SDRAM, 2 × 16 GB, Dual Channel
Industrial Ethernet 3 × Gigabit Ethernet, RJ45
Display Interfaces 2 × DisplayPort, 1 × DVI-D
Serial Interface 1 × COM1 RS-232; COM2 optional
USB Interfaces 4 × USB 3.1, 2 × USB 3.1 Type-C rear, 2 × USB 3.0 front, 1 × USB 3.1 internal
Audio Interfaces Microphone input, line input and line output
Storage RAID1, 2 × 4 TB Enterprise 3.5-inch SATA HDD
System Storage 512 GB M.2 NVMe SSD via PCIe x4 adapter card
Expansion Slots 3 × PCI, 1 × PCIe x16 (8-lane), 5 × PCIe x16 (4-lane), 2 × PCIe x4 (4-lane)
Total Expansion Slots 11 slots
Watchdog Supported
Temperature Monitoring Supported
Fan Monitoring Supported
Card Retainer Supported
Power Supply 100/240 V AC industrial power supply, autoranging, 50/60 Hz
Mains Buffering Approximately 20 ms
Industrial Ethernet Speed 10/100/1000 Mbps
Front Protection Rating IP41
Rear Protection Rating IP20
Operating System Windows 10 Enterprise 2016 LTSB, 64-bit, configuration-dependent
Application Industrial automation, SCADA, machine control, production monitoring and industrial data processing
Dimensions 444 × 430 × 177 mm
Weight 17 kg

FAQ

1. What is Siemens 6AG4114-3HE13-4BX1 used for?
Siemens 6AG4114-3HE13-4BX1 is a SIMATIC IPC847E 19-inch 4U industrial Rack PC designed for industrial automation, SCADA, machine control, production monitoring and industrial data processing applications.

2. Which processor is installed in the 6AG4114-3HE13-4BX1?
This configuration uses an Intel Core i7-8700 processor with 6 cores and 12 threads. It provides a 3.2 GHz base frequency, up to 4.6 GHz Turbo frequency and 12 MB cache, with support for Intel Turbo Boost, VT-d and AMT technologies.

3. How much memory does this industrial computer provide?
The 6AG4114-3HE13-4BX1 is configured with 32 GB DDR4 SDRAM using 2 × 16 GB modules in Dual Channel mode. The memory configuration is suitable for demanding industrial visualization, SCADA and data-processing applications.

4. What storage configuration does this model use?
The system uses two 4 TB Enterprise 3.5-inch SATA hard drives configured as RAID1 for data redundancy. It also includes a 512 GB M.2 NVMe SSD installed through a PCIe x4 adapter card for the operating system.

5. Which communication and I/O interfaces are available?
The computer provides 3 Gigabit Ethernet RJ45 interfaces for Industrial Ethernet and PROFINET communication, 1 COM1 RS-232 interface, 2 DisplayPort interfaces, 1 DVI-D interface, multiple USB interfaces and audio connections. COM2 can be provided as an optional RS-232 interface.

6. What expansion capabilities does the IPC847E provide?
The system provides an 11-slot expansion board configuration consisting of 3 PCI slots, 1 PCIe x16 slot with 8 lanes, 5 PCIe x16 slots with 4 lanes and 2 PCIe x4 slots with 4 lanes. This allows additional industrial communication, acquisition, motion-control or other PCI/PCIe cards to be installed according to system requirements.

7. How can a RAID1 or storage fault be diagnosed?
Check the RAID controller or system monitoring software for the status of both hard drives. If one drive is reported as failed or the RAID array enters a degraded state, verify the SATA connections and replace the affected drive with a compatible Enterprise-class drive. After replacement, allow the RAID1 array to rebuild and confirm that the rebuild completes successfully.

8. Can the 6AG4114-3HE13-4BX1 be integrated with Siemens PLC and PROFINET systems?
Yes. The three Gigabit Ethernet interfaces support Industrial Ethernet and PROFINET communication. The IPC can be used as a SCADA, HMI, data acquisition, visualization or supervisory computer alongside Siemens PLC systems, provided the installed operating system, drivers and automation software are correctly configured.

Siemens 6AG4114-3HE13-4BX1 Rack-Mount Industrial Computer is in stock. Please contact us for a quick quote and competitive pricing.
