Woodward 5461-290 Power Supply
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Woodward |
| Model / Part Number | 5461-290 |
| Product Type | High Voltage Power Supply |
| Power Supply Type | High-Voltage Power Supply |
| Design | Open-Frame |
| Status Indication | LED Status Indicators |
| Output – Meter / Actuator | 24 V |
| Output – Relay / FS | 211 V |
| Output – Transducer | 15 V |
| Typical Application | Woodward turbine and industrial control systems |
| Associated System | Woodward 505 / DCS control systems |
| Cooling Method | Natural convection |
| Installation | Industrial control cabinet / control system |
| Dimensions | 180 × 95 × 50 mm |
| Weight | 1.47 kg |
FAQ
1. What is the main function of the Woodward 5461-290 Power Supply?
The Woodward 5461-290 is a high-voltage power supply designed to provide the required electrical supply for specific control, relay, actuator, meter, and transducer circuits in Woodward control systems. It is intended for stable power delivery within industrial turbine and process-control applications.
2. What output voltages are associated with the 5461-290?
The available specifications identify 24 V for the meter/actuator circuit, 211 V for the relay/fail-safe circuit, and 15 V for the transducer circuit. These outputs serve different functions within the associated control architecture and should not be interchanged during wiring or replacement.
3. Is the 5461-290 a high-voltage power supply?
Yes. The 5461-290 is specifically identified as a high-voltage power supply. Because some of its output circuits operate at significantly different voltage levels, technicians should verify the terminal assignment and system wiring before applying power.
4. What type of construction does the Woodward 5461-290 use?
The unit is described as an open-frame power supply with LED status indicators. Its open-frame construction means that it should be installed within an appropriate protected control-system enclosure and should not be treated as a standalone enclosed power supply.
5. What should be checked before installing a 5461-290?
Check the part number, system compatibility, wiring documentation, terminal identification, grounding arrangement, and incoming power conditions. The connected loads should also be verified against the intended 24 V, 211 V, and 15 V circuits before commissioning.
6. What are common symptoms of a faulty 5461-290 power supply?
Typical symptoms can include loss of one or more control-system supply voltages, abnormal LED indications, failure of connected relays or actuators to operate, unstable transducer signals, or unexpected controller shutdowns. Troubleshooting should begin by measuring the relevant supply circuits and checking wiring and protection devices.
7. How can an output-voltage fault on the 5461-290 be diagnosed?
First isolate the affected circuit and follow the system safety procedure. Measure the incoming supply and then check the relevant output terminals under the conditions specified by the control-system documentation. If the input is correct but an expected output is missing or substantially abnormal, inspect connectors, wiring, downstream loads, and the power-supply assembly itself.
8. Can the Woodward 5461-290 be replaced directly with another power supply?
Replacement should not be based only on physical compatibility. The substitute must match the required voltage outputs, electrical characteristics, terminal configuration, load requirements, and control-system compatibility. The 5461-290 is also listed by current aftermarket references as discontinued, so any replacement or substitute should be verified against the original system documentation before installation.
Woodward 5461-290 Power Supply is in stock. Please contact us for a quick quote and competitive pricing.
