Allen-Bradley MPL-B210V-EJ72AA MP-Series Low-Inertia Rotary Servo Motor
The Allen-Bradley MPL-B210V-EJ72AA is a low-inertia brushless AC servo motor from Rockwell Automation’s MP-Series. Designed for precision motion control, it supports high-speed operation and accurate position feedback in industrial automation systems. Its compact 75 mm frame, keyed shaft, and rotatable right-angle connector make it suitable for compatible machinery and servo-drive applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Model | MPL-B210V-EJ72AA |
| Product Type | Low-Inertia Rotary Servo Motor |
| Product Series | MP-Series |
| Motor Technology | Brushless AC Servo |
| Voltage Class | 400 V class |
| Rated System Voltage | 460 V AC |
| Frame Size | 75 mm (2.95 in.) |
| Magnet Stack Length | 25.4 mm (1.0 in.) |
| Rated Speed | 8,000 RPM |
| Continuous Stall Torque | 0.55 N·m |
| Peak Torque | 1.5 N·m |
| Rated Output Power | Approximately 0.37 kW |
| Feedback Device | Single-turn high-resolution absolute encoder |
| Feedback Protocol | HIPERFACE |
| Shaft Type | Keyed shaft extension |
| Shaft Seal | No shaft seal |
| Holding Brake | No brake |
| Connector | 7-pin SpeedTEC DIN connector |
| Connector Orientation | Right-angle, 180° rotatable |
| Mounting Flange | IEC metric, free mounting holes (Type FF) |
| Protection Rating | IP50 |
| Maximum Operating Temperature | 40°C |
| Dimensions | 63 mm × 63 mm × 150 mm |
| Weight | Approximately 1.4 kg |
| Product Status | Active |
FAQ
Q1: What is the Allen-Bradley MPL-B210V-EJ72AA?
The MPL-B210V-EJ72AA is a low-inertia brushless AC servo motor designed for precise motion control in industrial automation systems.
Q2: What is the rated voltage of this motor?
It is designed for 460 V AC systems and belongs to the 400 V voltage class. Confirm compatibility with the servo drive before installation.
Q3: What are the rated speed and torque?
The motor has a rated speed of 8,000 RPM, continuous stall torque of approximately 0.55 N·m, and peak torque of approximately 1.5 N·m.
Q4: Does the MPL-B210V-EJ72AA include a holding brake?
No. This model is supplied without a holding brake. Applications that require load holding should be evaluated for a suitable external mechanical solution.
Q5: What type of encoder does this servo motor use?
It uses a single-turn high-resolution absolute encoder with HIPERFACE feedback, allowing a compatible servo drive to monitor motor position accurately.
Q6: What shaft and connector configurations does it have?
The motor features a keyed shaft extension and a right-angle SpeedTEC DIN connector that can rotate 180 degrees for flexible installation and cable routing.
Q7: What are the dimensions and weight of this motor?
The frame size is 75 mm, and the magnet stack length is 25.4 mm. The listed weight is approximately 1.4 kg. Consult the manufacturer’s mechanical drawing for exact dimensions and mounting measurements.
Q8: What should be checked before replacing this servo motor?
Verify the voltage class, encoder compatibility, shaft dimensions, mounting flange, connector orientation, torque requirements, and brake configuration. Confirm compatibility with the existing servo drive and machine before installation.
Allen-Bradley MPL-B210V-EJ72AA MP-Series Low-Inertia Rotary Servo Motor is in stock. Please contact us for a quick quote and competitive pricing.
