Allen-Bradley MPL-B1520U-HJ72AA MP-Series Rotary Servo Motor
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Manufacturer | Rockwell Automation |
| Model | MPL-B1520U-HJ72AA |
| Product Series | MP-Series MPL |
| Product Type | Low-Inertia Brushless Rotary Servo Motor |
| Voltage Class | 460 V AC |
| Frame Size | 63 mm |
| Magnet Stack Length | 50.8 mm (2.0 in.) |
| Rated Speed | 7000 RPM |
| Rated Output Power | 0.27 kW |
| Continuous Stall Torque | 0.49 N·m |
| Peak Stall Torque | 1.58 N·m |
| Feedback | 2000-line incremental encoder |
| Shaft Configuration | Keyed shaft, no shaft seal |
| Connector | Right-angle SpeedTEC DIN connector, rotatable 180° |
| Holding Brake | No brake |
| Mounting | IEC metric flange, Type FF |
| Enclosure Protection | IP50 standard; can reach IP66 with compatible shaft seal and connectors |
| Dimensions | 165 mm |
| Weight | Approximately 4.54 kg (10 lb) |
FAQ
Q1: What is the Allen-Bradley MPL-B1520U-HJ72AA?
It is a low-inertia brushless rotary servo motor from the Allen-Bradley MP-Series, designed for precise motion control in industrial automation systems.
Q2: What voltage class does this motor use?
It is designed for 460 V AC-class servo applications and requires a compatible servo drive.
Q3: What is its rated speed?
The motor has a rated speed of 7000 RPM, making it suitable for high-speed positioning and rotary motion applications.
Q4: Does this model include a holding brake?
No. The HJ72AA configuration is specified without a holding brake.
Q5: What feedback system does it use?
It uses a 2000-line incremental encoder to provide position feedback for closed-loop servo control.
Q6: What shaft and connector configuration does it have?
It has a keyed shaft without a shaft seal and a right-angle SpeedTEC DIN connector that can be rotated through 180 degrees.
Q7: Which applications are suitable for this servo motor?
Typical applications include packaging machinery, automated production equipment, material handling, and precision positioning systems.
Q8: How can the dimensions and weight be confirmed?
Consult the official Rockwell Automation dimensional drawing for the exact catalog number. The listed weight is approximately 4.54 kg; confirm the actual unit and packaging weight before shipping or installation.
Allen-Bradley MPL-B1520U-HJ72AA MP-Series Rotary Servo Motor is in stock. Please contact us for a quick quote and competitive pricing.
