Siemens 6AG1193-6BP00-7DA0 Base Unit
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Siemens |
| Model | 6AG1193-6BP00-7DA0 |
| Product Name | SIPLUS ET 200SP BaseUnit |
| Product Series | SIPLUS ET 200SP |
| Base Model | 6ES7193-6BP00-0DA0 |
| BaseUnit Type | BU15-P16+A0+2D |
| BU Type | A0 |
| Product Function | Base unit for connecting ET 200SP I/O modules and field wiring |
| Terminal Type | Push-in terminals |
| Number of Process Terminals | 16 |
| P1/P2 Bus Connection Terminals | 2 |
| AUX Terminals | No AUX terminals |
| Bridging Configuration | New load group; potential group configuration depends on the station layout |
| Rated Supply Voltage | 24 V DC |
| External Power Supply Protection | 24 V DC, 10 A miniature circuit breaker with B-type or C-type tripping characteristic |
| Maximum Current-Carrying Capacity | 10 A up to 60°C |
| Number of Slots | 1 |
| Potential Isolation | Between the backplane bus and supply voltage, and between potential groups |
| Isolation Test Voltage | 707 V DC |
| Conformal Coating | Yes |
| Operating Temperature | -40°C to +70°C under specified horizontal installation conditions |
| Minimum Startup Temperature | -25°C |
| Maximum Installation Altitude | Up to 5,000 m, subject to ambient temperature and atmospheric pressure restrictions |
| Compatible System | Siemens SIMATIC ET 200SP |
| Dimensions | 15 × 117 × 35 mm |
| Weight | 0.04 kg |
FAQ
Q1: What is the Siemens 6AG1193-6BP00-7DA0 BaseUnit used for?
A1: This SIPLUS ET 200SP BaseUnit connects compatible ET 200SP I/O modules to field wiring. It provides 16 process terminals and connections to the P1 and P2 backplane buses. It is a system component rather than a standalone PLC controller.
Q2: What type of terminals does this BaseUnit use?
A2: The 6AG1193-6BP00-7DA0 uses Push-in terminals for field wiring. Compatible conductors can be inserted directly into the terminals, simplifying installation and maintenance. Confirm the permitted conductor cross-section and wiring requirements before connecting the device.
Q3: What power supply does the 6AG1193-6BP00-7DA0 require?
A3: The specified rated supply voltage is 24 V DC. Siemens specifies external protection for the power supply lines using a 10 A miniature circuit breaker with a B-type or C-type tripping characteristic. The actual wiring and protection arrangement must follow the system design and product documentation.
Q4: What is the maximum current-carrying capacity of this BaseUnit?
A4: The specified maximum current-carrying capacity is 10 A at ambient temperatures up to 60°C. Ensure that the connected modules, wiring, and protective devices are suitable for the intended load. Do not exceed the applicable current limits of any connected component.
Q5: What is the difference between the SIPLUS model and the standard 6ES7193-6BP00-0DA0?
A5: The 6AG1193-6BP00-7DA0 is the SIPLUS version based on the standard 6ES7193-6BP00-0DA0. It features conformal coating and supports a specified operating temperature range of -40°C to +70°C under horizontal installation conditions. These features make it suitable for more demanding industrial environments, subject to the manufacturer’s installation restrictions.
Q6: Does the 6AG1193-6BP00-7DA0 include AUX terminals?
A6: No. This model does not have AUX terminals. It provides 16 process terminals and two terminals connected to the P1/P2 bus. If the application requires separate AUX connections, select a BaseUnit with the appropriate terminal configuration.
Q7: Can this BaseUnit be used with any SIMATIC ET 200SP I/O module?
A7: Compatibility depends on the I/O module, BaseUnit configuration, electrical requirements, and potential group arrangement. The 6AG1193-6BP00-7DA0 is a BU type A0 model. Check the module’s compatibility information and system wiring plan before installing it or using it as a replacement.
Q8: What should be checked when troubleshooting or replacing this BaseUnit?
A8: Confirm the full order number and the BU type A0 configuration. Inspect the 24 V DC supply, terminal connections, wiring condition, and the installation of the connected I/O module. If a fault persists, check the module configuration and potential group arrangement before returning the station to operation.
