Allen-Bradley 20G11LD800AN2NNNNN PowerFlex 755 AC Drive
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Model | 20G11LD800AN2NNNNN |
| Product Type | PowerFlex 755 AC Drive |
| Drive Series | PowerFlex 755 |
| Input Voltage | 480 V AC; verify nameplate |
| Input Phase | Three-phase |
| Duty Classification | Low Duty (LD) |
| Rated Output Current | Verify against the exact catalog specification |
| Motor Power Rating | Verify against the exact catalog specification |
| Cooling Method | Forced-air cooling |
| Communication | Embedded EtherNet/IP |
| Operator Interface | AN2 configuration; confirm exact HIM option |
| Enclosure Rating | Confirm from the manufacturer’s documentation |
| Dynamic Braking | Verify the exact configuration |
| Dimensions | 2477 × 1200 × 800 mm |
| Weight | 1287kg |
| Typical Applications | Industrial pumps, fans, compressors, conveyors, and motor-control systems |
FAQ
Q1: What is the Allen-Bradley 20G11LD800AN2NNNNN?
A: It is an Allen-Bradley PowerFlex 755 AC drive designed for variable-speed control of industrial motors. The exact catalog number identifies the drive’s electrical and configuration options.
Q2: What is the input voltage?
A: This model is associated with a 480 V AC, three-phase supply. Verify the drive nameplate and site power requirements before installation.
Q3: What is its rated output current?
A: The rated output current is 800 A.
Q4: What motor power ratings are available?
A: The PowerFlex 755 800 A rating is associated with 800 HP low duty, 700 HP normal duty, and 600 HP heavy duty. Confirm the applicable duty rating for the intended load.
Q5: Does it support EtherNet/IP?
A: Yes. The PowerFlex 755 family supports embedded EtherNet/IP for communication with compatible PLCs and industrial automation systems.
Q6: Does the AN2 version include an operator interface?
A: The AN2 configuration differs from the AN0 version. Confirm the exact HIM arrangement against the unit’s nameplate and catalog documentation before ordering or planning local operation.
Q7: What are the dimensions and weight?
A: The exact dimensions and weight should be obtained from the manufacturer’s mechanical drawing and technical documentation for this catalog number. Do not use measurements from a packaged-drive variant as a substitute.
Q8: What should be checked before replacing an existing drive?
A: Confirm the full catalog number, voltage, current and duty ratings, enclosure, CM jumper configuration, operator interface, braking requirements, communication settings, and installation dimensions. These checks help avoid incompatibility during commissioning.
Allen-Bradley 20G11LD800AN2NNNNN PowerFlex 755 AC Drive is in stock. Please contact us for a quick quote and competitive pricing.
