Schneider TCSEGPA23F14F Profibus DP V1 Remote Master
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Description |
|---|---|
| Manufacturer | Schneider Electric |
| Model | TCSEGPA23F14F |
| Product Name | Profibus DP V1 Remote Master |
| Product Series | Profibus DP |
| Product Type | Profibus DP V1 Remote Master Module |
| Communication Gateway | Ethernet Modbus TCP to PROFIBUS DP V1 |
| Compatible PLC Platforms | Modicon M340, M580, Premium, Quantum |
| Physical Interface | RS-485 |
| PROFIBUS Access Mode | Class 1 Master and Class 2 Master |
| Modbus TCP Access Mode | Slave |
| Transmission Mode | NRZ |
| PROFIBUS Connection | 9-pin SUB-D connector |
| Ethernet Connection | 2 × RJ45 Ethernet TCP/IP ports |
| PROFIBUS Transmission Rate | Up to 12 Mbit/s |
| Modbus TCP Transmission Rate | 10–100 Mbit/s |
| Maximum Number of PROFIBUS Slaves | 126 |
| PROFIBUS Cable Type | Two twisted shielded pairs |
| Modbus TCP Cable Type | Category 5 shielded twisted-pair (STP) cable |
| Power Supply | External 24 V DC |
| Current Consumption | 200 mA at 24 V DC |
| Configuration Software | Unity Pro with compatible PRM Master DTM and communication DTM |
| Module Format | Standard |
| Operating Temperature | 0–60°C |
| Storage Temperature | -45–85°C |
| Relative Humidity | 10–95%, non-condensing |
| Dimensions | 110 × 145 × 95 mm |
| Weight | 0.62 kg |
| Product Lifecycle | Scheduled for discontinuation on December 1, 2027; confirm current availability with the supplier |
FAQ
Q1: What is the main function of the Schneider Electric TCSEGPA23F14F?
A: The TCSEGPA23F14F is a PROFIBUS DP V1 Remote Master module. It connects compatible Schneider Electric PLC systems to PROFIBUS field devices through an Ethernet Modbus TCP interface, allowing the PLC to exchange process data with connected devices.
Q2: Which PLC platforms are compatible with the TCSEGPA23F14F?
A: The module is designed for Schneider Electric Modicon M340, M580, Premium, and Quantum PLC platforms. Before installation, verify compatibility with the specific PLC hardware, firmware, and programming environment.
Q3: How does the TCSEGPA23F14F communicate with PROFIBUS devices?
A: It uses an RS-485 physical interface and a 9-pin SUB-D connector for PROFIBUS DP V1 communication. It supports cyclic process-data exchange and acyclic DP V1 read/write communication where supported by the connected devices.
Q4: What is the role of the Ethernet ports on this module?
A: The two RJ45 Ethernet ports provide Modbus TCP connectivity between the remote master and the PLC network. The module operates as a Modbus TCP slave while managing communication with PROFIBUS devices.
Q5: How many PROFIBUS slave devices can the TCSEGPA23F14F support?
A: The specified maximum is 126 PROFIBUS slave devices. The practical configuration depends on the network design, device requirements, communication load, and supported system configuration.
Q6: What software is required to configure the TCSEGPA23F14F?
A: Configuration uses the PRM Master DTM and communication DTM within a compatible FDT/DTM environment. The product documentation identifies Unity Pro as the PLC configuration environment. Confirm software version compatibility before commissioning or modifying an existing system.
Q7: What should be checked if PROFIBUS communication fails?
A: Check the PROFIBUS cable and connector, bus termination, device addresses, baud-rate settings, slave configuration, and diagnostic information. Also verify the Ethernet connection, Modbus TCP configuration, and the PLC’s access to the module’s process data.
Q8: What should buyers consider when replacing or purchasing the TCSEGPA23F14F?
A: Confirm the full model number, PLC compatibility, required communication functions, included configuration software, and the condition of the module. Schneider Electric has announced a discontinuation date of December 1, 2027, so buyers maintaining existing systems should also check stock availability and long-term replacement options.
Schneider TCSEGPA23F14F Profibus DP V1 Remote Master is in stock. Please contact us for a quick quote and competitive pricing.
