Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | 5069-IY4 |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Type | Industrial Equipment |
| Product Series | Compact 5000 I/O |
| Module Type | Analog Output Module |
| Number of Outputs | 4 Channels |
| Output Signal Types | Current and Voltage |
| Voltage Output Range | 0–10V DC |
| Current Output Range | 0–20 mA, 4–20 mA |
| Resolution | 16-Bit |
| Output Accuracy | ±0.1% Full Scale |
| Settling Time | Approx. 1 ms per Channel |
| Isolation Voltage | 50V Continuous |
| Communication Protocol | EtherNet/IP via Adapter Module |
| Wiring Category | 2 – Analog Signal Ports |
| Terminal Type | Removable RTB (Removable Terminal Block) |
| Diagnostics | Short Circuit, Open Load Detection |
| Status Indicators | Module and Channel LEDs |
| Installation Method | DIN Rail Mount |
| Housing Type | Open-Type Industrial Module |
| Power Dissipation | Approx. 3.2 W |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Shock Resistance | 30 G Operating |
| Vibration Resistance | 5 G at 10–500 Hz |
| Dimensions (H × W × D) | Approx. 145 × 35 × 105 mm |
| Weight | Approx. 0.23 kg |
| Certifications | CE, UL, CSA, ATEX, IECEx, RCM |
| Application | Industrial Analog Signal Output Control |
| Lifecycle Status | Active Product |
FAQ
Q1: What is the primary function of the 5069-IY4 module?
A1: The 5069-IY4 is a 4-channel analog output module used for controlling industrial devices with voltage or current signals.
Q2: What types of output signals are supported?
A2: The module supports voltage outputs (0–10V DC) and current outputs (0–20 mA or 4–20 mA).
Q3: How many output channels are available?
A3: The module provides 4 independent analog output channels.
Q4: What is the resolution and accuracy of the module?
A4: The 5069-IY4 provides 16-bit resolution with ±0.1% full-scale accuracy.
Q5: Does the module include diagnostics?
A5: Yes. It features short circuit and open load detection for each channel, as well as module status LEDs.
Q6: Which controllers are compatible with this module?
A6: It is compatible with CompactLogix 5380 and ControlLogix 5580 platforms using Compact 5000 I/O systems.
Q7: How is the module installed in industrial systems?
A7: The 5069-IY4 is designed for DIN rail mounting inside control cabinets or distributed I/O panels.
Q8: What applications commonly use the 5069-IY4?
A8: It is used in process control, industrial automation, analog device control, and systems requiring precise output signals.
Allen Bradley 5069-IY4 Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
