Allen Bradley 1756-EN2TRXT ControlLogix-XT EtherNet/IP Bridging Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | ControlLogix-XT EtherNet/IP Bridging Module |
| Brand | Allen-Bradley |
| Model | 1756-EN2TRXT |
| Product Type | EtherNet/IP communication and bridging module |
| Main Function | Provides EtherNet/IP networking and bridging capability for ControlLogix-XT systems |
| Application | Industrial automation, harsh environment distributed control systems, industrial Ethernet networking |
| System Platform | Allen-Bradley ControlLogix-XT |
| Network Protocol | EtherNet/IP |
| Communication Role | Real-time deterministic communication and controller-to-controller data exchange |
| Network Interface | Dual-port industrial Ethernet interface |
| Topology Support | Star, linear, and Device Level Ring (DLR) capable |
| Data Types Supported | I/O data, explicit messaging, controller-to-controller communication |
| Installation Type | ControlLogix chassis-mounted module |
| Configuration Method | Studio 5000 engineering software |
| Diagnostics | Built-in network and module health diagnostics |
| Redundancy Support | Network and system redundancy support (system dependent) |
| Environmental Rating | XT (extended temperature / harsh environment design) |
| Operating Environment | Harsh industrial control cabinet environments |
| EMI Protection | Industrial-grade electromagnetic compatibility design |
| Structure Type | Ethernet bridging communication module |
| Dimensions | 144.5 × 34.6 × 130.18 mm |
| Weight | 0.39 kg |
FAQ
1. What is the main function of the 1756-EN2TRXT module?
The 1756-EN2TRXT module provides EtherNet/IP communication and bridging capabilities specifically designed for ControlLogix-XT systems. It enables high-speed, deterministic data exchange between controllers, I/O devices, and other Ethernet-enabled equipment, ensuring reliable industrial network performance even in harsh environments.
2. What does the “XT” designation indicate?
The “XT” designation indicates that the module is engineered for extended environmental conditions. It is designed to operate reliably in harsh industrial environments where standard modules may not perform consistently, such as areas with higher temperatures, vibration, or environmental stress.
3. What is the purpose of the bridging function?
The bridging function allows data to be transferred between different controllers or network segments within an EtherNet/IP architecture. This enables multiple ControlLogix systems to operate as a unified distributed control system with synchronized communication.
4. Where is this module typically used?
This module is commonly used in oil and gas facilities, petrochemical plants, power generation stations, mining operations, and other heavy industrial environments where reliable Ethernet communication in harsh conditions is required.
5. What types of communication does it support?
It supports cyclic I/O communication for real-time control, explicit messaging for configuration and diagnostics, and controller-to-controller communication for system integration and coordination.
6. Does it support network redundancy?
Yes, the module supports redundant network configurations depending on system design. This helps maintain communication continuity in case of network path failures, improving overall system availability.
7. How is the module configured?
Configuration is performed using Rockwell Automation Studio 5000 software. Engineers define IP settings, communication parameters, network topology, and device relationships within the engineering environment.
8. What factors can affect EtherNet/IP performance in harsh environments?
Performance can be influenced by electromagnetic interference, cable quality, network congestion, improper grounding, and harsh environmental conditions. Proper industrial design and adherence to XT installation guidelines are essential for stable operation.
Allen Bradley 1756-EN2TRXT ControlLogix-XT EtherNet/IP Bridging Module is in stock. Please contact us for a quick quote and competitive pricing.
