Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Address Reserve Module |
| Model Number | 1769-ARM |
| Series | Allen-Bradley Compact I/O |
| Module Type | Expansion Bus Address Reserve Module |
| Function | Reserve Slot Addressing in Compact I/O Systems |
| Compatible Systems | CompactLogix and MicroLogix 1500 Systems |
| Mounting Type | DIN Rail or Panel Mount |
| Installation Position | Compact I/O Bank Expansion |
| Backplane Current Draw | Approx. 5 mA @ 5V DC |
| Power Dissipation | Approx. 0.02 W |
| Isolation Voltage | 30V Continuous |
| Wiring Requirements | No Field Wiring Required |
| Communication | Internal Compact I/O Bus |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Shock Resistance | 30 g Operational |
| Vibration Resistance | 5 g @ 10–500 Hz |
| Dimensions (L × W × H) | Approx. 118 × 50 × 87 mm |
| Weight | Approx. 0.14 kg |
| Key Features | Compact address reserve module used to maintain I/O slot numbering and future expansion space in Compact I/O systems without requiring active circuitry or field wiring |
FAQ
- What is the 1769-ARM used for?
It is an address reserve module used to maintain slot numbering and reserve positions for future I/O expansion in Compact I/O systems. - Does the module provide any actual I/O functions?
No, the 1769-ARM does not provide input or output functionality; it only reserves addressing space. - Which systems are compatible with this module?
It is compatible with CompactLogix and MicroLogix 1500 systems using 1769 Compact I/O modules. - Is field wiring required?
No, the module does not require any field wiring connections. - Why is address reservation important?
It helps maintain stable I/O addressing and simplifies future system expansion or module replacement. - How is the module installed?
It mounts directly on the Compact I/O DIN rail or panel mounting system like standard 1769 modules. - Is the 1769-ARM still active?
Yes, Rockwell Automation continues to support the 1769-ARM for Compact I/O systems.
Allen Bradley 1769-ARM Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
