Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | 2085-IF4 |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Type | Industrial Equipment |
| Series | Micro800 Expansion I/O Modules |
| Module Type | Analog Input Module |
| Number of Inputs | 4 Analog Inputs |
| Input Signal Type | Voltage / Current |
| Voltage Input Range | ±10V, 0–10V |
| Current Input Range | 0–20 mA, 4–20 mA |
| Resolution | 14-bit |
| Conversion Type | SAR |
| Input Impedance | >1 MΩ (Voltage), <100 Ω (Current) |
| Isolation | Isolated Channels |
| Data Format | 16-bit Two’s Complement |
| Update Rate | <2 ms per enabled channel |
| Accuracy | ±0.10% Full Scale at 25°C |
| Status Indicators | LED Status Indicators |
| Mounting Type | DIN Rail / Panel Mount |
| Enclosure Rating | IP20 |
| Operating Temperature | -20°C to 65°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Dimensions (H × W × D) | 90 × 28 × 87 mm |
| Weight | Approx. 0.14 kg |
| Power Dissipation | Approx. 1.7 W |
| Wiring Connection | Removable Terminal Block |
| Country of Origin | Singapore |
| Compliance Standards | CE, UL, RoHS |
FAQ
Q1: What is the main purpose of the 2085-IF4 module?
A1: The 2085-IF4 is designed to expand Micro800 PLC systems by providing four analog input channels for voltage and current signal monitoring.
Q2: Which controllers are compatible with the 2085-IF4?
A2: The module is compatible with Allen-Bradley Micro850 and Micro870 programmable controllers.
Q3: What signal types can the 2085-IF4 process?
A3: It supports both analog voltage and current signals, including ±10V, 0–10V, 0–20 mA, and 4–20 mA ranges.
Q4: Does the module provide channel isolation?
A4: Yes. The 2085-IF4 includes isolated analog channels to improve signal stability and reduce electrical interference.
Q5: Is the module suitable for industrial environments?
A5: Yes. It is engineered for industrial automation applications and operates reliably under demanding environmental conditions.
Q6: How is the 2085-IF4 installed?
A6: The module can be mounted directly onto a DIN rail or installed using panel mounting methods within a control cabinet.
Q7: What is the resolution of the analog inputs?
A7: The module offers 14-bit analog resolution, allowing accurate signal acquisition for process monitoring and control applications.
Q8: Does the 2085-IF4 require calibration after installation?
A8: No. The module is factory-calibrated, and no additional user calibration is normally required during commissioning.
Allen Bradley 2085-IF4 Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
