Epro PR6423/10R-040-HT+CON021 Industrial Equipment
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | PR6423/10R-040-HT + CON021 |
| Product Type | Industrial Equipment |
| Manufacturer | EPRO / Emerson |
| Product Series | PR6423 Eddy Current Sensor System |
| System Type | High Temperature Non-contact Eddy Current Displacement Measurement System |
| Sensor Model | PR6423/10R-040-HT |
| Signal Converter Model | CON021 |
| Measurement Principle | Eddy Current technology |
| Main Function | Shaft displacement, vibration, position, eccentricity and speed monitoring in high-temperature rotating machinery |
| Probe Diameter | 8 mm |
| Measurement Range | ±1 mm |
| Initial Air Gap | Approx. 1.5 mm |
| Sensitivity | 8 V/mm |
| Linearity Error | ≤ ±1% |
| Target Material | Ferromagnetic steel |
| Minimum Shaft Diameter | ≥25 mm |
| Cable Type | High temperature resistant cable |
| Sensor Cable Length | Approx. 4 m |
| Sensor Tip Material | High temperature resistant material |
| Sensor Housing Material | Stainless steel |
| Sensor Operating Temperature | -35°C to +180°C |
| Converter Operating Temperature | -30°C to +100°C |
| Converter Supply Voltage | -23 to -32 VDC |
| Converter Output Signal | Voltage output for monitoring systems |
| Converter Protection Class | IP20 |
| Connection Type | LEMO connector and terminal connection |
| Application | High-temperature turbines, compressors, pumps, gearboxes and critical rotating machinery |
| Dimensions | Approx. 8 mm diameter × 50 mm length |
| Weight | Approx. 0.3 kg |
FAQ
Q: What is the PR6423/10R-040-HT + CON021 mainly used for?
A: The system is designed for non-contact shaft displacement and vibration monitoring in rotating equipment operating under high-temperature conditions.
Q: What components are included in the PR6423/10R-040-HT + CON021 system?
A: The system consists of the PR6423/10R-040-HT high-temperature eddy current sensor and the CON021 signal converter for signal conditioning and monitoring applications.
Q: What is the main advantage of the PR6423/10R-040-HT sensor?
A: It is designed for harsh environments with elevated temperatures, providing stable displacement measurement for critical machinery.
Q: How does the PR6423/10R-040-HT work?
A: The sensor uses eddy current technology to measure the distance between the probe tip and the rotating shaft without physical contact.
Q: What is the function of the CON021 converter?
A: The CON021 provides sensor excitation, signal processing and output conversion for PR6423 series eddy current sensors.
Q: What equipment can use the PR6423/10R-040-HT + CON021 system?
A: It is commonly applied to steam turbines, gas turbines, compressors, pumps, fans and other critical rotating equipment.
Q: Does the PR6423/10R-040-HT require direct contact with the shaft?
A: No. The sensor performs non-contact measurement, reducing mechanical wear and allowing continuous online monitoring.
Q: What factors affect measurement accuracy?
A: Proper installation gap, correct shaft material, stable converter operation, cable condition and suitable operating temperature are important for reliable measurement performance.
Epro PR6423/10R-040-HT+CON021 Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
