Schneider STBXBE1300K Internal Bus Expansion Kit
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Name | BOS Internal Bus Expansion Kit |
| Model | STBXBE1300K |
| Product Range | Modicon STB Distributed I/O Solution |
| Product Type | Internal Bus Expansion Kit |
| Expansion Module | STBXBE1300 BOS Module |
| Mounting Location | Beginning of an extension segment |
| Compatibility | Standard Modicon STB modules |
| Kit Components | STBXBE1300 BOS module, STBXBA2300 size 2 base, STBXTS1120 two-terminal screw connector, STBXTS2120 two-terminal spring-clamp connector |
| Rated Supply Voltage | 24 V DC |
| Supply Voltage Range | 19.2–30 V DC |
| Input Current | 400 mA |
| Logic Bus Output Voltage | 5.25 V DC ±0.21% |
| Power Supply Output Current | 1.2 A |
| Electrical Connections | 2-pin removable power-supply connector; FireWire interface |
| Protection Rating | IP20 |
| Overvoltage Category | II |
| Pollution Degree | 2 |
| Operating Altitude | Up to 2000 m |
| Storage Temperature | -40–85°C |
| Relative Humidity | Up to 95% at 60°C, non-condensing |
| Electromagnetic Compatibility | Immunity to electromagnetic interference according to IEC 61131-2 |
| Certifications | CE, UL, CSA, FM Class I Division 2 |
| Dimensions | 120 × 18.4 × 70 mm |
| Weight | 0.1 kg |
FAQ
Q1: What is the main function of the Schneider Electric STBXBE1300K?
The STBXBE1300K is a BOS internal bus expansion kit for the Modicon STB distributed I/O system. It extends the internal communication bus to an additional I/O segment, allowing compatible STB modules to operate as part of the same distributed automation island.
Q2: Where should the STBXBE1300K be installed?
The kit is installed at the beginning of an extension segment. Correct positioning is important for maintaining internal bus communication between the primary segment and the additional segment. Follow the system layout and installation instructions when arranging the modules.
Q3: Which components are included in the STBXBE1300K kit?
The kit includes the STBXBE1300 BOS module, an STBXBA2300 size 2 mounting base, an STBXTS1120 two-terminal screw connector, and an STBXTS2120 two-terminal spring-clamp connector. Check that all required components are present before installation.
Q4: What power supply requirements apply to the STBXBE1300K?
The kit uses a nominal 24 V DC supply and supports an input voltage range of 19.2–30 V DC. Its specified input current is 400 mA, and the logic bus output is 5.25 V DC ±0.21%, with a power supply output current of 1.2 A. Verify the power distribution arrangement and total system load before commissioning.
Q5: Why might communication fail between the primary and extension segments?
Check that the BOS module is installed at the correct location, the mounting base is secure, and the internal bus interface is properly connected. Also verify the power supply, connector seating, and compatibility of the installed STB modules. Incorrect assembly or a loose connection can interrupt communication across the extension segment.
Q6: Can the STBXBE1300K be used with any Modicon STB module?
It is designed for standard Modicon STB modules. However, compatibility should be checked against the complete I/O island configuration, including the network interface module, power distribution components, and other expansion modules. Do not assume compatibility with unrelated product families.
Q7: What should be checked if the extension segment does not power up?
Measure the incoming DC supply and confirm that it remains within the specified 19.2–30 V DC range. Inspect the removable power connector, terminal wiring, mounting base, and power distribution components. If the voltage is correct but the segment remains inactive, isolate the fault by checking connected modules and consulting the system diagnostics.
Q8: What should be verified before replacing an STBXBE1300K?
Confirm the exact model and compatibility with the existing Modicon STB system. Before removing the module, follow the required shutdown and electrical isolation procedures. Inspect the mounting base, power connectors, and internal bus connections during replacement. After installation, restore power according to the system procedure and verify that the extension segment communicates correctly before returning the equipment to service.
