Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Schneider Electric |
| Product Name | Easy Modicon M200 Controller |
| Model | TM200C40T |
| Product Series | Easy Modicon M200 |
| Product Type | Programmable Logic Controller (PLC) |
| Total Digital I/O | 40 points |
| Digital Inputs | 24 inputs, 24 V DC |
| High-Speed Inputs | 4 inputs for high-speed counting (HSC) |
| Fast Inputs | 4 inputs for fast counting (FC) |
| Regular Inputs | 16 digital inputs |
| Digital Outputs | 16 transistor outputs |
| Output Configuration | 14 regular transistor outputs and 2 fast outputs |
| Output Type | Source transistor outputs (PNP) |
| Rated Supply Voltage | 24 V DC |
| Supply Voltage Range | 20.4–28.8 V DC |
| Rated Output Voltage | 24 V DC |
| Maximum Current per Output | 0.5 A |
| Fast Output Functions | PWM, PLS and PTO |
| Maximum Fast Output Frequency | 100 kHz for PWM/PLS mode |
| Communication Interface | Built-in RS-485 serial link |
| Programming Port | USB Mini-B |
| Ethernet Port | Not available on this model |
| Maximum Power Consumption | 18 W at 24 V DC with maximum I/O load |
| Expansion Capability | Supports up to 4 compatible I/O expansion modules, subject to configuration limits |
| Mounting Type | DIN rail mounting |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to 55°C, subject to installation conditions |
| Dimensions | 175 × 90 × 70 mm |
| Weight | 0.522 kg |
FAQ
1. What is the main function of the Schneider Electric TM200C40T controller?
The TM200C40T is a programmable logic controller designed for small and medium-sized automation applications. It processes input signals, executes control programs, and operates connected devices through its transistor outputs.
2. How many inputs and outputs does the TM200C40T provide?
The controller provides 40 digital I/O points, consisting of 24 digital inputs and 16 transistor outputs. Its inputs include high-speed and fast-counting channels, while two outputs support high-speed pulse functions.
3. What power supply does the TM200C40T require?
The controller requires a nominal 24 V DC supply, with an allowable voltage range of 20.4–28.8 V DC. Use a suitable regulated power supply and verify the polarity and wiring before powering on the unit.
4. What is the difference between the TM200C40T and TM200C40U?
The TM200C40T uses source-type transistor outputs (PNP), whereas the TM200C40U uses sink-type transistor outputs (NPN). The correct model depends on the wiring configuration and the electrical requirements of the connected loads.
5. Does the TM200C40T support high-speed counting and motion-related functions?
Yes. It provides four high-speed inputs for HSC functions, four fast inputs for fast counting, and two fast transistor outputs supporting PWM, PLS, and PTO functions. The fast outputs support frequencies up to 100 kHz in PWM/PLS mode, subject to configuration and operating conditions.
6. What communication interfaces are available on the TM200C40T?
The controller includes an RS-485 serial communication interface and a USB Mini-B programming port. It does not have a built-in Ethernet port, so applications requiring direct Ethernet communication should use a suitable alternative model or compatible external solution.
7. Can the TM200C40T be expanded with additional I/O modules?
Yes. The Easy Modicon M200 platform supports compatible expansion modules. The controller can accommodate up to four expansion modules, but the permitted I/O capacity depends on the module type and system configuration. Verify compatibility before adding hardware.
8. How should an output fault be diagnosed on the TM200C40T?
Check the 24 V DC supply, PLC operating status, program logic, output address, wiring polarity, and load current. Each transistor output is rated at up to 0.5 A. Confirm that the connected load is suitable for PNP source outputs and that the wiring and protection arrangements meet the manufacturer’s requirements.
