Siemens 6AG1193-6BP20-7BA0 Base Unit
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Siemens |
| Model | 6AG1193-6BP20-7BA0 |
| Product Name | SIPLUS ET 200SP Base Unit |
| Product Type | BU Type A0 |
| Product Designation | BU15-P16+A10+2B |
| Based On | 6ES7193-6BP20-0BA0 |
| Product Family | SIPLUS ET 200SP |
| Main Function | Provides electrical connections and mounting for compatible ET 200SP I/O modules |
| Rated Supply Voltage | 24 V DC |
| Terminal Type | Push-in terminals |
| Process Terminals | 16 |
| AUX Terminals | 10, internally bridged to the left |
| P1/P2 Bus Terminals | 2 |
| Maximum Current Carrying Capacity | 10 A |
| Maximum Process Terminal Current | 2 A |
| Maximum P1/P2 Bus Current | 10 A |
| Maximum AUX Bus Current | 10 A |
| Conductor Cross-Section | 0.14–2.5 mm² |
| Potential Separation | Yes, between the backplane bus and supply voltage |
| Insulation Test Voltage | 707 V DC |
| Operating Temperature | -40 to +70°C (horizontal installation) |
| Conformal Coating | Yes, for enhanced environmental protection |
| Load Group Configuration | Dark BaseUnit for continuing an existing load group |
| Mounting Method | DIN rail mounting within the ET 200SP station |
| Dimensions | 15 × 141 × 35 mm |
| Weight | 0.05 kg |
FAQ
Q1: What is the main function of the Siemens 6AG1193-6BP20-7BA0 Base Unit?
A: The 6AG1193-6BP20-7BA0 is a SIPLUS ET 200SP Base Unit designed to mount compatible I/O modules and provide electrical connections between field wiring, the I/O module, and the system bus. It serves as the physical wiring interface within a distributed I/O station.
Q2: Which ET 200SP I/O modules are compatible with this Base Unit?
A: This Base Unit is designed for compatible ET 200SP I/O modules that require a BU Type A0 interface. Before installation, check the I/O module’s specified BaseUnit type and terminal arrangement to ensure mechanical and electrical compatibility.
Q3: What is the difference between the BU15-P16+A10+2B and other ET 200SP Base Units?
A: The BU15-P16+A10+2B provides 16 process terminals, 10 AUX terminals and two P1/P2 bus connections. Its AUX terminals are internally bridged to the left. It is a dark BaseUnit intended to continue an existing load group rather than start a new one.
Q4: What type of wiring connection does the 6AG1193-6BP20-7BA0 use?
A: It uses Push-in terminals, allowing compatible conductors to be inserted directly into the terminal points. The specified conductor cross-section is 0.14–2.5 mm². Ensure that the conductor type and preparation comply with Siemens installation requirements.
Q5: What is the maximum current capacity of this Base Unit?
A: The maximum current-carrying capacity is 10 A under the specified conditions. The P1/P2 and AUX buses support up to 10 A, while the process terminals have a maximum current rating of 2 A. Appropriate external protection must be provided for the 24 V DC supply.
Q6: Can the 6AG1193-6BP20-7BA0 operate in harsh industrial environments?
A: Yes. As a SIPLUS Base Unit, it features conformal coating and an extended operating temperature range of -40 to +70°C under specified horizontal installation conditions. It is designed for demanding industrial environments involving humidity, dust and chemically active substances. Installation and operation must still follow the environmental limits in the Siemens documentation.
Q7: What should be checked if an ET 200SP I/O module does not communicate after installation?
A: First, verify that the BaseUnit is correctly mounted and that the I/O module is fully seated. Then check the 24 V DC supply, P1/P2 bus connections, terminal wiring and module compatibility. Inspect the station diagnostics in the PLC engineering software to identify configuration errors or communication faults.
Q8: What should be considered when replacing a faulty 6AG1193-6BP20-7BA0 Base Unit?
A: Select a replacement with the same BU Type A0 and terminal configuration. Confirm the 16 process terminals, 10 AUX terminals and left-side AUX bridging arrangement. Also verify that the replacement is a dark BaseUnit suitable for continuing the existing load group. Before replacement, isolate the power supply and label the field wiring to avoid connection errors.
