Siemens 6AG1193-6BP20-7BB0 Base Unit
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Siemens |
| Model Number | 6AG1193-6BP20-7BB0 |
| Product Name | SIPLUS ET 200SP Base Unit |
| Product Type | BU Type B0 |
| Product Designation | BU20-P12+A4+0B |
| Based On | 6ES7193-6BP20-0BB0 |
| Product Family | SIPLUS ET 200SP |
| Main Function | Provides electrical connections for ET 200SP I/O modules and field wiring |
| Terminal Type | Push-in terminals |
| Number of Process Terminals | 12 |
| Number of AUX Terminals | 4, internally bridged to the left |
| Load Group Configuration | Dark BaseUnit for continuing an existing load group |
| Rated Supply Voltage | 24 V DC |
| Maximum Current Carrying Capacity | 10 A |
| Conductor Cross-Section | 0.14–2.5 mm² (AWG 26–14) |
| Potential Separation | Yes, between the backplane bus and supply voltage |
| Insulation Test Voltage | 3,250 V DC |
| Operating Temperature | -40 to +70°C (horizontal installation) |
| Maximum Operating Temperature | +50°C (vertical installation) |
| Protective Coating | Conformal coating for enhanced environmental protection |
| Number of Slots | 1 |
| Mounting Method | DIN rail mounting within the ET 200SP station |
| Dimensions | 20 × 117 × 35 mm |
| Weight | 0.048 kg |
FAQ
Q1: What is the main function of the Siemens 6AG1193-6BP20-7BB0 Base Unit?
A: The 6AG1193-6BP20-7BB0 is a SIPLUS ET 200SP Base Unit used to connect compatible I/O modules to field wiring and the station’s electrical bus system. It provides the physical terminal interface for signal and auxiliary connections in a distributed automation system.
Q2: Which ET 200SP modules are compatible with this Base Unit?
A: It is designed for ET 200SP I/O modules that require a BU Type B0 BaseUnit. Always check the module’s installation requirements and Siemens compatibility information before fitting it, as different BaseUnit types have different terminal layouts and electrical arrangements.
Q3: How many connection terminals does the 6AG1193-6BP20-7BB0 provide?
A: It provides 12 process terminals for the I/O module and four additional AUX terminals. The AUX terminals are internally bridged to the left, allowing the auxiliary potential to be distributed through the designated connections.
Q4: What is the difference between a B0 BaseUnit and a B1 BaseUnit?
A: The B0 version, BU20-P12+A4+0B, has 12 process terminals and four internally bridged AUX terminals. The B1 version, BU20-P12+A0+4B, has 12 process terminals but no additional AUX terminals. Both are dark BaseUnits intended to continue an existing load group.
Q5: What wiring technology does this Base Unit use?
A: The 6AG1193-6BP20-7BB0 uses Push-in terminals. Compatible conductors can be inserted directly into the terminals, reducing wiring time. The specified conductor cross-section is 0.14–2.5 mm². Check the conductor type and preparation requirements before installation.
Q6: Can the 6AG1193-6BP20-7BB0 be used in harsh industrial environments?
A: Yes. This SIPLUS BaseUnit features conformal coating and an extended operating temperature range. It is specified for -40 to +70°C in horizontal installation and up to +50°C in vertical installation. Actual suitability depends on the installation orientation and the environmental limits specified by Siemens.
Q7: What should be checked if an I/O module installed on this BaseUnit fails to operate?
A: Check that the I/O module is fully seated and correctly matched to the BU Type B0 interface. Then inspect the 24 V DC supply, P1/P2 bus connections, field wiring and AUX connections. If the hardware appears correct, review the PLC diagnostics for module configuration errors or station-level faults.
Q8: What should be considered when replacing the 6AG1193-6BP20-7BB0?
A: The replacement should match the BU Type B0 configuration and the original terminal arrangement: 12 process terminals and four AUX terminals bridged to the left. Also confirm that the replacement is suitable for continuing the existing load group. Isolate the power supply before removing the unit, label the field wiring and verify compatibility with the installed I/O module before commissioning.
