Siemens 6AG1193-6BP20-7DC0 Base Unit
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Siemens |
| Model Number | 6AG1193-6BP20-7DC0 |
| Product Name | SIPLUS ET 200SP BaseUnit |
| Product Type | BU Type C0 |
| Product Designation | BU20-P6+A2+4D |
| Base Model | 6ES7193-6BP20-0DC0 |
| Product Family | SIPLUS BaseUnits |
| Main Function | Provides a mounting interface and field wiring terminals for ET 200SP I/O modules |
| Load Group Configuration | Light BaseUnit for starting a new load group |
| Number of Process Terminals | 6 |
| Number of AUX Terminals | 2 |
| Terminal Type | Push-in terminals |
| Rated Supply Voltage | 24 V DC |
| P1/P2 Power Bus | Supports power potential distribution |
| AUX Bus | Supports auxiliary potential distribution |
| Conductor Cross-Section | 0.14–2.5 mm² (AWG 26–14) |
| Maximum Current Carrying Capacity | 10 A, subject to wiring and operating conditions |
| Potential Separation | Electrical separation according to the ET 200SP system design |
| Insulation Test Voltage | 3,100 V DC |
| Environmental Protection | Conformal coating for enhanced protection in industrial environments |
| Operating Temperature (Horizontal Installation) | -40 to +60°C |
| Operating Temperature (Vertical Installation) | -25 to +50°C |
| Protection Rating | IP20 when installed in the ET 200SP system |
| Mounting Method | Installation on the ET 200SP system rail |
| Dimensions | 20 × 117 × 35 mm |
| Weight | 0.047 kg |
FAQ
Q1: What is the main function of the Siemens 6AG1193-6BP20-7DC0 BaseUnit?
A: This product is a BaseUnit for the SIPLUS ET 200SP distributed I/O system. It is used to mount compatible I/O modules and provide electrical connections between the modules and field devices. It also supports power and auxiliary potential distribution, making it an important wiring component in an ET 200SP station.
Q2: What type of BaseUnit is the 6AG1193-6BP20-7DC0?
A: This model belongs to BU Type C0, with the product designation BU20-P6+A2+4D. It features a light-colored BaseUnit with six process terminals and two AUX terminals. It is designed to start a new load group.
Q3: How many connection terminals does this BaseUnit provide?
A: The 6AG1193-6BP20-7DC0 provides six process terminals for connections to the I/O module and two AUX terminals for auxiliary potential distribution. The process terminals handle field signal connections, while the AUX terminals are used for auxiliary electrical distribution. Always refer to the relevant I/O module wiring diagram when assigning signals and power connections.
Q4: How does the 6AG1193-6BP20-7DC0 differ from other ET 200SP BaseUnits?
A: The main differences are the terminal count, BaseUnit type and load group configuration. For example, a BU Type B0 BaseUnit provides 12 process terminals and four AUX terminals, whereas the C0 version provides six process terminals and two AUX terminals. The C0 is a light BaseUnit for starting a new load group. Selection should be based on module compatibility and the required wiring layout, not just the external appearance.
Q5: What wiring method does this product use, and which conductor sizes are supported?
A: This model uses Push-in terminals, allowing compatible rigid conductors and conductors with suitable ferrules to be connected directly. The supported conductor cross-section is 0.14–2.5 mm² (AWG 26–14). Before wiring, check the conductor type, stripping length and terminal requirements to ensure a secure electrical connection.
Q6: Is the 6AG1193-6BP20-7DC0 suitable for harsh industrial environments?
A: Yes. This SIPLUS product features conformal coating and is designed for industrial environments where humidity and certain environmental contaminants may be present. Its specified operating temperature range is -40 to +60°C for horizontal installation and -25 to +50°C for vertical installation. Always check the installation orientation and environmental limits before commissioning.
Q7: How should I troubleshoot an I/O module that does not operate correctly after installation?
A: First, check that the module is correctly installed on the C0 BaseUnit and that the module is compatible with this BaseUnit type. Then inspect the 24 V DC supply, P1/P2 power bus, AUX terminals and field signal wiring. If the wiring is correct, use the PLC engineering software to review ET 200SP station diagnostics and identify possible module configuration errors or backplane bus faults.
Q8: What should I consider when replacing a faulty 6AG1193-6BP20-7DC0?
A: Select the same BU Type C0 configuration or a replacement confirmed by Siemens as compatible. Check the six process terminals, two AUX terminals and light-colored BaseUnit design. Since this model is used to start a new load group, also confirm that its position and power grouping match the original system design. Before removal, isolate the relevant power supply and label all field wires. After installation, verify the wiring, module configuration and station diagnostics before restoring operation.
