Allen-Bradley MPL-B320P-SJ72AA Low-Inertia Servo Motor
The Allen-Bradley MPL-B320P-SJ72AA is a low-inertia brushless AC servo motor from Rockwell Automation’s MP-Series MPL family. Designed for precision motion control, it combines a 5000 RPM rated speed, a single-turn high-resolution encoder, and a keyed shaft for reliable mechanical coupling. Its right-angle SpeedTEC DIN connector can rotate through 180°, providing flexibility when installing the motor in industrial machinery.
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Manufacturer | Rockwell Automation |
| Model | MPL-B320P-SJ72AA |
| Product Type | Low-inertia brushless AC servo motor |
| Product Series | MP-Series MPL |
| Voltage Class | 460 V AC |
| Frame Size | 100 mm (3.94 in.) |
| Magnet Stack Length | 50.8 mm (2.0 in.) |
| Rated Speed | 5000 RPM |
| Continuous Stall Torque | Approximately 3.05 Nm |
| Peak Stall Torque | Approximately 7.91 Nm |
| Continuous Stall Current | Approximately 4.5 A |
| Peak Stall Current | Approximately 14.0 A |
| Feedback Device | Single-turn high-resolution encoder |
| Encoder Protocol | Hiperface |
| Encoder Resolution | 1024 Sin/Cos cycles per revolution |
| Shaft Type | Keyed shaft extension |
| Connector | SpeedTEC DIN, right-angle, 180° rotatable |
| Holding Brake | No brake |
| Mounting | IEC metric, Type FF free mounting holes |
| Enclosure Protection | IP50 minimum without shaft seal; IP66 possible with optional shaft seal and environmentally sealed cable connectors |
| Operating Temperature | 0–40°C |
| Storage Temperature | -30–70°C |
| Relative Humidity | 5–95%, non-condensing |
| Dimensions | 100 mm frame size; 50.8 mm magnet stack length. Overall dimensions depend on the mechanical drawing and should be confirmed before installation. |
| Weight | Approximately 3.7 kg (8.0 lb) |
| UPC | 820919980510 |
FAQ
Q1: What is the Allen-Bradley MPL-B320P-SJ72AA?
It is a low-inertia brushless AC servo motor designed for precise speed, position, and torque control in industrial automation systems.
Q2: What is the rated speed of this servo motor?
The rated speed is 5000 RPM, making it suitable for applications requiring responsive and accurate motion.
Q3: Does the MPL-B320P-SJ72AA include a holding brake?
No. This model is supplied without an integrated holding brake. Applications requiring brake-based holding should use a compatible brake-equipped model.
Q4: What feedback system does it use?
The motor uses a single-turn high-resolution encoder with Hiperface feedback, supporting accurate position and motion control.
Q5: What type of shaft does this model have?
It has a keyed shaft extension, which helps transmit torque through a compatible coupling or mechanical drive connection.
Q6: Which connector is fitted to the motor?
It uses a right-angle SpeedTEC DIN connector that can rotate through 180°, helping accommodate different cable-routing and installation requirements.
Q7: What are its dimensions and weight?
The motor has a 100 mm frame and a 50.8 mm magnet stack, with a listed weight of approximately 3.7 kg. Check the model-specific mechanical drawing for the complete overall dimensions and mounting clearances.
Q8: What should be checked before replacing or installing this motor?
Confirm the voltage class, servo-drive compatibility, encoder feedback requirements, shaft and coupling dimensions, connector and cable compatibility, mounting arrangement, and whether the application requires a holding brake. Also inspect the motor nameplate and mechanical drawing before commissioning.
Allen-Bradley MPL-B320P-SJ72AA Low-Inertia Servo Motor is in stock. Please contact us for a quick quote and competitive pricing.
