Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 1756-OF8H |
| Product Type | High-Performance Analog Output Module |
| Category | ControlLogix I/O Module |
| System Compatibility | ControlLogix chassis |
| Function | Provides 8-channel high-resolution analog output control for precision process applications |
| Output Channels | 8 channels |
| Output Types | Voltage or Current (configurable per channel) |
| Voltage Output Range | ±10 VDC |
| Current Output Range | 0–20 mA / 4–20 mA |
| Resolution | 16-bit high-resolution D/A conversion |
| Accuracy | High accuracy (typically ±0.05–0.1% full scale, application dependent) |
| Backplane Interface | ControlLogix backplane |
| Update Time | Fast update per channel (application dependent, typically ~1 ms or better) |
| Isolation Voltage | 250 V continuous (channel-to-backplane) |
| Diagnostics | Enhanced channel diagnostics and status monitoring |
| Calibration | Factory calibrated with software trim capability |
| Wiring | Requires Removable Terminal Block (RTB) |
| RTB Compatibility | 1756-TBCH / 1756-TBS6H |
| Power Consumption | ~5–7 W |
| Current Draw | ~300–400 mA @ 5.1 VDC |
| Module Width | 1 slot |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Dimensions (H × W × D) | Approx. 145 mm × 35 mm × 140 mm |
| Weight | Approx. 0.3–0.4 kg |
| Lifecycle Status | High-performance / industrial analog output module |
FAQ
What is the 1756-OF8H used for?
It is a high-performance analog output module used for precision control of industrial process signals.
How is it different from OF8?
The “H” version typically indicates higher performance and improved accuracy, making it suitable for more demanding applications.
What signals does it output?
It supports ±10 VDC voltage and 4–20 mA / 0–20 mA current outputs.
How many channels does it have?
It has 8 analog output channels.
What applications is it used in?
High-precision process control such as chemical dosing, turbine control, advanced motion/process regulation, and instrumentation systems.
Is it isolated?
Yes, it provides channel-to-backplane isolation for improved noise immunity.
Does it require configuration?
Yes. Each channel is configurable in Studio 5000 for voltage or current output modes.
