1762-IQ32T Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 1762-IQ32T |
| Product Type | Digital Input Module |
| Category | MicroLogix Expansion I/O |
| System Compatibility | MicroLogix 1100 / 1200 / 1400 / 1500 |
| Function | Provides high-density digital input acquisition |
| Input Channels | 32 digital inputs |
| Input Type | 24 VDC sink/source (depending on wiring configuration) |
| Input Voltage Range | 20.4–26.4 VDC |
| Input Current | ~6–8 mA per point (typical) |
| Input Response Time | Fast ON/OFF response (ms level) |
| Isolation | Channel-to-backplane isolation |
| Backplane Interface | MicroLogix 1762 expansion bus |
| Power Supply | 24 VDC (via base controller backplane) |
| Current Consumption | ~80–100 mA @ 5 VDC backplane power |
| Wiring | Removable terminal block (1762 RTB) |
| Mounting | DIN rail mount |
| Configuration | RSLogix 500 |
| LED Indicators | Individual channel status + module status |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Dimensions (H × W × D) | Approx. 90 mm × 40 mm × 87 mm |
| Weight | ~0.2–0.3 kg |
| Lifecycle Status | Active / widely used |
FAQ
What is the 1762-IQ32T used for?
It is a high-density digital input module used to collect ON/OFF signals from field devices in MicroLogix systems.
How many inputs does it have?
It provides 32 digital input channels.
What type of signals does it accept?
24 VDC digital signals (sink/source wiring depending on configuration).
What does the “T” mean?
It typically indicates a transistor-style input module variant optimized for fast digital signal processing.
Which PLCs is it compatible with?
MicroLogix 1100, 1200, 1400, and 1500 controllers.
Is it isolated?
Yes, it provides channel-to-backplane isolation for noise protection.
What software is used?
RSLogix 500.
Where is it used?
High-density input applications such as:
- Conveyor systems
- Packaging machines
- Large machine I/O monitoring
- Discrete signal collection systems
Is it standalone?
No. It must be used with a MicroLogix controller via the 1762 expansion bus.
