1768-EWEB Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 1768-EWEB |
| Product Type | EtherNet/IP Web Server Module |
| Category | CompactLogix Communication Module |
| System Compatibility | 1768 CompactLogix controllers |
| Function | Provides embedded web server and Ethernet communication services |
| Network Type | EtherNet/IP (Ethernet Industrial Protocol) |
| Ethernet Port | 1 × RJ45 10/100 Mbps auto-negotiation |
| Web Server Function | Built-in web pages for diagnostics and monitoring |
| Supported Services | HTTP, CIP messaging, diagnostics access |
| Programming Access | Remote diagnostics via web interface |
| Data Access | Controller tags accessible via web pages |
| Messaging | EtherNet/IP explicit messaging support |
| Backplane Interface | 1768 CompactLogix backplane |
| Configuration Software | RSLogix 5000 / Studio 5000 |
| IP Configuration | BOOTP/DHCP or static IP |
| Email Function | Not supported |
| Data Logging | Not native (requires controller logic) |
| Security | Basic access control (no modern encryption) |
| Power Consumption | ~2–3 W |
| Backplane Current | ~0.25–0.4 A @ 5 VDC |
| Isolation | Ethernet-to-backplane isolation |
| Mounting | 1768 CompactLogix chassis module slot |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Dimensions (H × W × D) | 132 mm × 56 mm × 105 mm |
| Weight | ~0.28 kg |
| Lifecycle Status | Discontinued / legacy product |
FAQ
What is the 1768-EWEB used for?
It is an Ethernet web server module used in CompactLogix systems for remote diagnostics and web-based monitoring.
What does it actually do?
- Hosts embedded web pages for PLC status
- Allows remote monitoring of controller tags
- Provides Ethernet communication access for diagnostics
Does it support EtherNet/IP?
Yes, it fully supports EtherNet/IP explicit messaging and diagnostics communication.
Can it be used for programming the PLC?
No, it is not used for programming, only monitoring and communication.
Does it support secure web access?
No, it only supports basic HTTP access, without modern encryption or security layers.
What is it typically used for?
- Remote troubleshooting
- Maintenance monitoring
- Industrial SCADA visualization (basic)
- Asset status checking over Ethernet
What system is it used with?
It is used with 1768 CompactLogix controllers.
What software is used with it?
RSLogix 5000 / Studio 5000 for configuration of controller side, not for the web module itself.
Is it still in production?
No, it is a discontinued legacy module, but still found in older automation systems.
Allen Bradley 1768-EWEB Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
