1769-ADN Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 1769-ADN |
| Product Type | Industrial Equipment |
| Category | DeviceNet Adapter Module |
| System Compatibility | CompactLogix 1769 / MicroLogix 1500 |
| Function | Connects Compact I/O system to DeviceNet network |
| Network Type | DeviceNet (CAN-based industrial network) |
| Communication Rates | 125 kbps / 250 kbps / 500 kbps |
| Protocol | CIP (Common Industrial Protocol) |
| Max Nodes Supported | Up to 63 DeviceNet nodes |
| I/O Capacity | Up to ~512 I/O points (network dependent) |
| Power Supply | 24 VDC |
| Connector Type | 5-pin DeviceNet connector |
| Backplane Interface | 1769 Compact I/O backplane |
| Communication Role | Adapter (slave device) |
| Mounting | DIN rail or panel mount |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Dimensions (H × W × D) | 123 mm × 25 mm × 64 mm |
| Weight | ~0.3–0.4 kg |
| Lifecycle Status | Discontinued / legacy product |
FAQ
What is the 1769-ADN used for?
It is an Industrial Equipment DeviceNet adapter module used to connect a CompactLogix 1769 I/O rack to a DeviceNet network.
What does it do?
- Acts as a DeviceNet slave (adapter)
- Connects local I/O modules to a DeviceNet master
- Enables distributed I/O communication
Is it a scanner or an adapter?
It is an adapter (slave device), not a scanner.
How many devices can it support?
Up to 63 nodes on a DeviceNet network.
What communication speeds are supported?
- 125 kbps
- 250 kbps
- 500 kbps
Where is it typically used?
- Remote I/O systems
- DeviceNet-based automation networks
- Assembly lines
- Legacy industrial systems
What is its main advantage?
- Enables distributed I/O architecture
- Reduces wiring complexity
- Integrates CompactLogix with DeviceNet devices
Is it still in production?
No, it is a discontinued legacy product, still used in existing systems.
Allen Bradley 1769-ADN Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
