1769-IF4 Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 1769-IF4 |
| Product Type | Industrial Equipment |
| Category | Compact I/O Analog Input Module |
| System Compatibility | CompactLogix 1769 / MicroLogix 1500 |
| Function | General-purpose analog input module |
| Number of Inputs | 4 differential channels |
| Input Signal Types | Voltage (V) or Current (mA), configurable |
| Voltage Ranges | 0–10 V, ±10 V |
| Current Ranges | 0–20 mA, 4–20 mA |
| Resolution | 16-bit |
| Conversion Time | ~8–20 ms per channel (typical) |
| Input Impedance | High impedance (voltage mode), ~250 Ω (current mode) |
| Isolation | Channel-to-backplane isolation |
| Backplane Interface | 1769 Compact I/O backplane |
| Power Supply | Backplane powered |
| Channel Configuration | Software selectable per channel |
| Calibration | Factory calibrated, software scaling supported |
| Mounting | DIN rail or panel mount |
| Slot Requirement | 1 slot |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Vibration | 5 g (10–500 Hz) |
| Shock | 30 g operating |
| Dimensions (H × W × D) | 118 mm × 35 mm × 87 mm |
| Weight | ~0.25–0.3 kg |
| Lifecycle Status | Active Mature / widely used legacy module |
FAQ
What is the 1769-IF4 used for?
It is a 4-channel analog input module used to read voltage or current signals in CompactLogix systems.
What signals does it support?
It supports both:
- Voltage signals (0–10 V, ±10 V)
- Current signals (4–20 mA, 0–20 mA)
Each channel can be configured independently.
How many channels does it have?
👉 4 analog input channels
Is it flexible compared to other IF modules?
Yes.
👉 It is more flexible than single-type modules like IF16V or IF16C because it supports both voltage and current inputs.
What is the resolution?
- 16-bit resolution, suitable for industrial process control and instrumentation.
Does it require external power?
No.
👉 Powered directly from the 1769 backplane
Where is it typically used?
- Small process control systems
- Machine-level instrumentation
- Retrofit or compact control panels
- Signal acquisition applications
Is it isolated?
Yes.
It provides channel-to-backplane isolation for noise immunity.
Is it still in production?
Yes, it is classified as Active Mature, still widely used in installed CompactLogix systems.
