1769-IQ16F Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 1769-IQ16F |
| Product Type | Industrial Equipment |
| Category | Compact I/O Fast DC Digital Input Module |
| System Compatibility | CompactLogix 1769 |
| Function | High-speed DC digital input module for fast signal detection |
| Number of Inputs | 16 channels |
| Input Type | 24 VDC fast digital inputs |
| Input Voltage Range | 10–30 VDC |
| On-State Voltage | ≥ 10 VDC |
| Off-State Voltage | ≤ 5 VDC |
| Input Current | ~5 mA per point |
| Input Delay (On/Off) | ~0.05–0.1 ms (ultra-fast response) |
| Isolation | Group-to-backplane isolation |
| Grouping | 2 input groups |
| Backplane Interface | 1769 Compact I/O backplane |
| Power Supply | Backplane powered |
| Special Feature | Fast response for high-speed signals |
| Mounting | DIN rail or panel mount |
| Slot Requirement | 1 slot |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Vibration | 5 g (10–500 Hz) |
| Shock | 30 g operating |
| Dimensions (H × W × D) | 118 mm × 35 mm × 87 mm |
| Weight | ~0.25–0.3 kg |
| Lifecycle Status | Active Mature |
FAQ
What is the 1769-IQ16F used for?
It is a 16-channel fast DC digital input module designed for applications requiring high-speed signal detection.
What makes it different from 1769-IQ16?
| Model | Response Speed |
|---|---|
| 1769-IQ16 | ~0.5–1 ms |
| 1769-IQ16F | ~0.05–0.1 ms (10× faster) |
👉 IQ16F is designed for high-speed input signals
What signals does it accept?
- 24 VDC fast ON/OFF signals
- High-speed sensors:
- Encoder pulses (low-speed applications)
- Proximity sensors
- High-speed switches
How many inputs does it have?
👉 16 digital input channels
Does it replace a high-speed counter?
No.
👉 It is faster than standard DI, but not a replacement for dedicated HSC modules
Where is it typically used?
- Packaging machines
- High-speed sorting systems
- Assembly automation
- Timing-sensitive industrial processes
Does it require external power?
No.
👉 Powered via the 1769 backplane
Is it still in production?
Yes.
👉 Classified as Active Mature, used in many CompactLogix systems requiring faster input response.
