1769-PA4 Technical Specifications
Allen‑Bradley 1769‑PA4 CompactLogix Power Supply
| Parameter | Specification |
|---|---|
| Model | 1769-PA4 |
| Product Type | Industrial Equipment |
| Category | CompactLogix Power Supply |
| System Series | 1769 Compact I/O System |
| Function | AC power supply for CompactLogix I/O and controller systems |
| Input Voltage Range | 85–265 VAC |
| Input Frequency | 47–63 Hz |
| Output Voltage | 5 VDC (backplane power) / 24 VDC (field power, system dependent) |
| Output Current | Up to ~4 A @ 5 VDC backplane |
| Power Capacity | ~30–40 W typical system load support |
| Backplane Support | Up to 16–30 1769 modules (depending on load) |
| Efficiency | High-efficiency switching design |
| Isolation | Input-to-output isolation |
| Protection | Overcurrent, overvoltage, thermal protection |
| LED Indicators | Power, fault, system status |
| Mounting | DIN rail / panel mount (CompactLogix chassis integration) |
| Cooling | Convection cooling (no fan) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Dimensions (H × W × D) | ~118 × 50 × 87 mm |
| Weight | ~0.3–0.5 kg |
| Lifecycle Status | Active Mature / legacy-compatible |
Key Features
- AC input CompactLogix system power supply
- Provides regulated 5V backplane power for 1769 I/O modules
- Compact design for panel-mounted industrial control systems
- Built-in electrical protections (overcurrent / overvoltage / thermal)
- Supports medium to large CompactLogix I/O configurations
- Convection-cooled (no fan required for reliability)
Typical Applications
- CompactLogix PLC systems power distribution
- 1769 I/O expansion racks
- Industrial automation control panels
- Machine control systems requiring stable DC backplane power
- Retrofit and upgrade of legacy Allen-Bradley systems
Summary
The 1769-PA4 is a CompactLogix AC power supply module designed to provide stable backplane power for 1769 I/O systems. It is commonly used in industrial control panels where reliable power distribution for PLC and I/O modules is required.
Allen Bradley 1769-PA4 Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
