Allen Bradley 1783-US4T1H/B Industrial Equipment
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | 1783-US4T1H/B Stratix 2000 Unmanaged Ethernet Switch |
| Product Type | Industrial Equipment |
| Series | Stratix 2000 |
| Device Type | Unmanaged Industrial Ethernet Switch |
| Network Type | Industrial Ethernet |
| Total Ports | 5 Ports |
| Copper Ports | 4 × 10/100 Mbps RJ45 Fast Ethernet |
| Fiber Ports | 1 × 100 Mbps Singlemode Fiber Port |
| Fiber Connector | LC Connector |
| Fiber Standard | 100BASE-FX |
| Fiber Wavelength | 1310 nm |
| Maximum Fiber Distance | Up to 20 km |
| Switching Mode | Unmanaged plug-and-play operation |
| Network Speed | 10/100 Mbps Ethernet |
| Broadcast Storm Protection | Supported |
| Power Input | 12–48V DC or 18–30V AC |
| Nominal Voltage | 24V DC |
| Maximum Power Consumption | Approx. 3.4 W |
| Maximum Inrush Current | Approx. 1.69 A |
| Isolation Voltage | 30V continuous isolation |
| Mounting Type | DIN rail mount |
| Enclosure Rating | IP20 |
| Cooling Method | Fanless passive cooling |
| Operating Temperature | -40°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5%–95% non-condensing |
| Dimensions (H × W × D) | Approx. 114.5 × 76.8 × 29.6 mm |
| Weight | Approx. 0.26 kg |
| Typical Applications | Long-distance industrial Ethernet communication, PLC networking, machine automation systems, industrial fiber uplinks |
FAQ
What is the 1783-US4T1H/B used for?
It is an unmanaged industrial Ethernet switch designed for industrial automation networks requiring both copper and long-distance singlemode fiber communication.
How many ports are available on this switch?
It includes 5 ports in total: 4 RJ45 Fast Ethernet ports and 1 singlemode fiber port.
Does the switch support long-distance fiber communication?
Yes, the singlemode fiber port supports transmission distances up to approximately 20 km.
Is the 1783-US4T1H/B a managed switch?
No, it is an unmanaged plug-and-play switch that operates without configuration software.
What power input range does it support?
It supports industrial power input ranges of 12–48V DC or 18–30V AC.
Can it operate in harsh industrial environments?
Yes, it is designed for demanding industrial conditions with an operating temperature range from -40°C to 70°C.
Does the switch use active cooling fans?
No, it uses a fanless passive cooling design for reliable low-maintenance operation.
Where is the 1783-US4T1H/B commonly installed?
It is commonly installed in factory automation systems, industrial Ethernet cabinets, PLC communication networks, and applications requiring fiber uplink connectivity.
Allen Bradley 1783-US4T1H/B Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
