1769-ASCII Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 1769-ASCII |
| Product Type | Industrial Equipment |
| Category | ASCII Communication Module |
| System Compatibility | CompactLogix 1769 / MicroLogix 1500 |
| Function | Provides serial ASCII communication between PLC and external devices |
| Channels | 2 independent serial channels |
| Communication Interfaces | RS-232 / RS-422 / RS-485 |
| Communication Type | ASCII protocol (pre-configured) |
| Transmission Mode | Full-duplex (RS-232) / Half-duplex (RS-422/485) |
| Data Length | Up to 200 characters per message |
| Communication Role | Serial gateway module |
| Backplane Interface | 1769 Compact I/O backplane |
| Power Supply | Backplane powered |
| Error Handling | Handshake error, RX overflow, FIFO overflow, data flag handling |
| Mounting | DIN rail or panel mount |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Dimensions (H × W × D) | 118 mm × 35 mm × 87 mm |
| Weight | ~0.25–1.0 kg |
| Lifecycle Status | Discontinued / legacy product |
FAQ
What is the 1769-ASCII used for?
It is an Industrial Equipment ASCII communication module used to connect PLC systems with serial devices that use ASCII-based communication.
What does it do?
- Sends and receives ASCII data
- Interfaces PLC with serial devices (barcode readers, printers, instruments)
- Acts as a serial communication gateway
What communication ports does it support?
- RS-232
- RS-422
- RS-485
How many channels does it have?
It has 2 independent serial channels, each configurable separately.
Is it Ethernet or fieldbus based?
No.
It is pure serial ASCII communication only.
What are typical applications?
- Barcode scanners
- Label printers
- Weighing instruments
- Serial sensors and analyzers
- Legacy industrial devices
What is its main advantage?
- Direct integration of ASCII devices into PLC systems
- Flexible support for multiple serial standards
- Eliminates need for external serial converters
Are there any limitations?
- Only supports ASCII protocol
- Limited message handling features
- Legacy communication technology
Is it still in production?
No, it is a discontinued legacy module, but still widely used in existing installations.
Allen Bradley 1769-ASCII Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
