1769-ECR Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 1769-ECR |
| Product Type | Industrial Equipment |
| Category | CompactLogix End Cap / Terminator |
| System Compatibility | CompactLogix 1769 / MicroLogix 1500 |
| Function | Terminates the right end of the 1769 I/O communication bus |
| Position in System | Right-end termination module |
| Electrical Role | Completes backplane communication circuit |
| Power Consumption | ~5 mA @ 5 VDC |
| Backplane Load | Very low (signal termination only) |
| Communication Role | Passive termination device (no processing function) |
| Installation Requirement | Required for proper I/O bus operation |
| Mounting | Installed at right end of 1769 I/O bank |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Vibration | 5 g (10–500 Hz) |
| Shock | 20–30 g depending on mounting |
| Dimensions (H × W × D) | ~118 mm × 87 mm × 15 mm |
| Weight | ~0.25–0.30 kg |
| Lifecycle Status | Active Mature |
FAQ
What is the 1769-ECR used for?
It is a right end cap (terminator) used in CompactLogix 1769 systems to properly terminate the I/O backplane communication bus.
What does it do?
- Closes the right side of the 1769 I/O rack
- Ensures correct backplane signal termination
- Maintains stable communication across I/O modules
Is it active or intelligent?
No.
👉 It is a passive termination module with no processing or communication capability.
Do I always need it?
Yes.
A complete 1769 I/O bank requires:
- 1769-ECL (left end cap)
- 1769-ECR (right end cap)
What happens if it is missing?
- Backplane communication fault
- I/O modules not detected
- System startup failure or diagnostic errors
Where is it installed?
It is installed at the rightmost end of the 1769 I/O rack.
Is it still in production?
Yes, it is still available and classified as Active Mature, widely used in installed CompactLogix systems.
Allen Bradley 1769-ECR Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
