1769-ECL Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 1769-ECL |
| Product Type | Industrial Equipment |
| Category | CompactLogix End Cap / Terminator |
| System Compatibility | CompactLogix 1769 / MicroLogix 1500 |
| Function | Terminates the left end of the 1769 I/O communication bus |
| Position in System | Left-end termination module |
| Electrical Role | Completes backplane communication circuit |
| Power Consumption | ~5 mA @ 5 VDC |
| Backplane Load | Very low (signal termination only) |
| Communication Role | Passive termination device (no data processing) |
| Installation Requirement | Required for proper system bus operation |
| Mounting | Installed at left end of 1769 I/O bank |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Vibration | 5 g (10–500 Hz) |
| Shock | 20–30 g depending on mounting |
| Dimensions (H × W × D) | ~118 mm × 87 mm × 15 mm |
| Weight | ~0.25–0.30 kg |
| Lifecycle Status | Active Mature |
FAQ
What is the 1769-ECL used for?
It is a left end cap / terminator used in CompactLogix 1769 systems to properly terminate the I/O backplane communication bus.
What does it actually do?
- Closes the left side of the 1769 I/O rack
- Ensures correct backplane signal termination
- Prevents communication errors in the I/O bus
Is it active or intelligent?
No.
👉 It is a passive hardware termination module with no processing function.
Do I need it in every system?
Yes, if you are using a 1769 I/O bank.
👉 A system requires:
- Left end cap (1769-ECL)
- Right end cap (e.g., 1769-ECR)
What happens if it is missing?
- I/O communication failure
- System fault on backplane
- Modules may not be recognized
Where is it installed?
It is installed at the leftmost side of the 1769 I/O rack.
Is it still in production?
Yes, it is still available and considered Active Mature, used widely in existing CompactLogix systems.
