Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | 1783-NATR Configurable Network Address Translation Router |
| Product Type | Industrial Equipment |
| Series | Stratix / ControlLogix Networking Series |
| Device Type | NAT Router (Network Address Translation Device) |
| Function | Industrial network address translation between private and public networks |
| Network Ports | 3 × RJ45 Ethernet ports |
| Port Configuration | 2 × private ports + 1 × public (external) port |
| Network Speed | 10/100 Mbps Ethernet |
| NAT Type | 1:1 Network Address Translation |
| Max Translation Capacity | Up to 32–100 mappings (configuration dependent) |
| Protocol Support | EtherNet/IP, TCP/IP, HTTP, ICMP, DNS |
| Redundancy Support | Linear and Device Level Ring (DLR) topologies |
| Power Input | 24V DC (20.4–27.6V DC) |
| Power Consumption | Approx. 3 W |
| Current Draw | Approx. 150 mA |
| Mounting Type | DIN rail mount |
| Enclosure Type | Open-style industrial module |
| Isolation | Electrical isolation between power and network ports |
| Operating Temperature | -25°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5%–95% non-condensing |
| Dimensions (H × W × D) | Approx. 132 × 140 × 105 mm |
| Weight | Approx. 0.34–0.38 kg |
| Typical Applications | Machine networking, PLC network segmentation, IP address translation in industrial Ethernet systems |
FAQ
What is the main function of the 1783-NATR?
It is a configurable NAT router used to translate IP addresses between a private industrial network and a plant-wide or external network without readdressing devices.
How many Ethernet ports does it have?
It has 3 RJ45 ports: 2 for the private network side and 1 for the public network side.
What type of NAT does it perform?
It performs 1:1 Network Address Translation, mapping private IPs directly to corresponding public IPs.
Is it only a router or does it include switching functions?
It includes embedded switch technology to support industrial topologies like linear and Device Level Ring (DLR).
What power supply does it require?
It operates on a 24V DC industrial power supply.
What is the operating temperature range?
It is designed for industrial environments ranging from -25°C to 70°C.
Can it be used in EtherNet/IP systems?
Yes, it supports EtherNet/IP and is commonly used in Rockwell Automation PLC networks.
Where is it commonly used?
It is typically used in factory automation, machine-level networking, and systems requiring secure segmentation between machine and plant networks.
Allen Bradley 1783-NATR Industrial Equipment is in stock. Please contact us for a quick quote and competitive pricing.
